Longitudinally Welded Stainless Steel Tubes BS6323-8 LW 12b LWCF 20 LWCF

Name: Longitudinally Welded Stainless Steel Tubes BS6323-8 LW 12b LWCF 20 LWCF
Brand: Torich
SKU: 149730324
Availability: InStock

Torich International Co.,ltd

US$ 2000 - 6000 MOQ: 1 Piece

Key Specifications

Brand Name:

Torich

Place of Origin:

China

Model Number:

BS6323-8

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name Torich

Place of Origin China

Model Number BS6323-8

Delivery Time:30-45days
Certification:GB/T 19001-2008,ISO 9001:2008,TS16949

Seamless and Welded Steel Tubes for Automobile, mechanical and General Engineering Purposes

Part 8: Specific requirements for longitudinally welded stainless steel tubes

Method of Manufacture:

The tubes are manufactured from flat rooled strip, longitudinally welded across the abutting edges without the addition of filler metal.

Delivery condition:

a) As-welded and sized: KM

b) Welded and sized (fully softened): GKW(S)

c) Welded and sized (fully softened) (including de-scaling): GZF(S)

d) Cold finished(fully softened): GBK

e) Cold finished(fully softened) (including de-scaling): GZF(S)

Steel Grade and Chemical Compositions:
Note: Special steel grade is also available, according to customer request

Mechanical properties
Designation	BS 1449-2: equivalent	KM (as welded)	GKM(S),GZF(S)(welded and sized fully softened)	GBK (S),and GZF(S)(cold finished ,fully softened)
Re min.	Rm min.	A min.	Re min.	Rm min.	A min.	Re min.	Rm min.	A min.
N/mm2	N/mm2	%	N/mm2	N/mm2	%	N/mm2	N/mm2	%
LW 12b		300	400	10	_	_	_	_	_	_
LW 19b	409S19	300	400	10	200	350	20	_	_	_
LW 20	304S11	420	520	25	185	480	30	_	_	_
LWCF 20								185	480	30
LW 21	304S15	450	560	25	210	510	30	_	_	_
LWCF 21								210	510	30
LW 22	316S13	420	520	25	185	480	30	_	_	_
LWCF 22								185	480	30
LW 23	316S33	450	560	25	210	510	30	_	_	_
LWCF 23
