Lightweight P16mm Football Stadium LED Displays Boards , Sports LED Advertising Screen
The stadium screens and sports displays are masters in showing publicity and game scores.With a public of
a complete stadium plus that the gams are showed on television the quality has to be superb. Our in stadium
LED advertising is powered by the horizontal viewing angle to more than 160 degrees. With such a super
wide viewing angle it increases the amount of spectators, and also multiple advertisements that can be
showed at once.
Application
The stadium led displays are widely used in the football field, basketball court, swimming center and diving center. And the functions of the stadium led displays include:
1.Show function: Can display various languages and several formats texts, and realize the live broadcast;
ction of time and score: Through the electronic referee, the screen can realize the function of time and score of the basketball and volleyball race. And show the name of the race team, the score goals, the name of the athletes who make the goal, substitution, red and yellow warning card sand other information;
3.Information processing function: can add up the score and fouls automatically; And when the athletes break the record, the screen can show the notice and make congratulations.
4.Emergency treatment function: The stadium led displays are used for the significant political activities, so it must has the emergency treatment function, when there is something wrong with the internet, the display can work still. And all the automatic function of the screen should can be switch to manual adjusted.
Specifications:
|
P16 Full Color Display |
|
|
Physical Pixel Pitch |
16mm |
|
Module Size |
256*128 |
|
Pixel Density |
3906/㎡ |
|
Pixel Configuration |
1R1G1B DIP346 |
|
Best Viewing Distance |
14m |
|
View Angle(Horizontal) |
110° |
|
Brightness |
≥7500cd/㎡ |
|
Driving Method |
Scan Constant Current Driving |
|
Control Mode |
Real Pixel |
|
Cabinet Size |
1024*768mm |
|
Cabinet Resolution |
64*48 |
|
Cabinet Weight |
60kg |
|
Maximum Power Consumption |
1000W/㎡ |
|
Operating Voltage |
220±10% or 110±10% |
Sport Perimeter LED Displays for Stadiums
The soccer field stadium sport perimeter LED displays will bring about a recurring revenue stream for any
operator or sponsor that have engaged on our products. Our sport perimeter led displays edit any live
streams, advertisement or perform any scoreboard function on real time basis.
In addition our system could be installed over different types of ground surfaces rather than only cement
based surface as can be seen with other sport perimeter LED displays. This will turn into saving installation
costs and a better viewing by the audience.
Stadium Screens and Refresh Rate Frequency
The refresh rate frequency for our stadium screens, sports displays, football stadium screens and perimeter
displays is over 800 Hz, so no static will be shown when recorded by a television camera and broad casted
on television. This means that with a high refresh rate frequency our stadium screens and sports displays
can display flicker free video images, which includes live video feeds.
Product Features
High impact-resistance: Silicon rubber mask of tile can absorb the impact from balls or players.
The top protective hat of the tile also uses soft materials to protect the pl
