P16 Outdoor Advertising Curved LED Screen , Photo High - Definition Pixel LED Display
Certification:CE RoHS
P16 Outdoor Advertising Curved LED Screen , Photo High - Definition Pixel LED Display
Specifications:
|
Physical Pixel Pitch |
16mm |
|
Module Size |
256*128 |
|
Pixel Density |
3906/㎡ |
|
Pixel Configuration |
1R1G1B DIP346 |
|
Best Viewing Distance |
14m |
|
View Angle(Horizontal) |
110° |
|
Brightness |
≥7500cd/㎡ |
|
Driving Method |
Scan Constant Current Driving |
|
Control Mode |
Real Pixel |
|
Cabinet Size |
1024*768mm |
|
Cabinet Resolution |
64*48 |
|
Cabinet Weight |
60kg |
|
Maximum Power Consumption |
1000W/㎡ |
|
Operating Voltage |
220±10% or 110±10% |
Product Features
■ The indoor series from D-King boasts wider viewing angles, and the enhanced surface, for an exceptional
picture quality in any indoor setting;
■ With a light output more than 1,200 nits and native 16-bit color processing, it is sure to deliver the
pinnacle of image quality in all circumstances;
■ The module design and slim casing make installation simple, featured in seamless and lightweight.
■Very high-definition display with outstanding image and video quality.
High refresh rate(greater than 400Hz) with software adjustable, suitable for filming,
■High Greyscale with superior color uniformity
Wide viewing angle(greater than 110 ° in horizontal)
Low power consumption
■High reliability and long lifespan(MTBF≥10000hours)
IP rating with the back IP43, the front IP65
Fast and easy to install and dismantle
Note:
Our company products are constantly upgrading, the above parameters is for reference only, please refer
to the actual parameters prevail.
