Ultra Pulse Co2 Fractional Laser Skin Tightening Machine 100um - 2000um Spot Size

Delivery Time:7-10 working days
Certification:Medical CE
Ultra Pulse Co2 Fractional Laser Skin Tightening Machine 100um - 2000um Spot Size
 Treatment theory:

Fractional laser light penetrates the skin with tiny thermal channels through the random scanning. This creates an ablative and thermal effect on only these channels (a micro-injury) without damaging the surrounding tissue. The tissue surrounding the micro-injury sites (about 15-20% of the treatment area) starts the process of healing. As collagen remodels, skin tightened, scars improved and pigmented lesions removed.




Application   l Application Range of Fractional treatment handpiece:

1. Large pores, Fine lines, Skin tightening and whitening, Skin loosen(Deep Wrinkles), Stretch marks.
2. Various Scars:Burn Scars, Acne Scars, Surgical Scars and Keloid.Pigmented skin lesions:Chloasma, Freckles, Age spots, Sun spots, CAMLS.
3. Reconstruction of photoaging skin.



ll Application Range of Incision handpiece:

1. Via multiple handles it can be adapted to Gynecology, ENT, Neurology and general surgery.
2. In Cosmetic Surgery, it can be adapted to incisions for Blepharoplasty, Skin Tags and Ingrown Nails, Compound Nevus and Intra Dermal Nevus etc.



YILIYA-10600AL Advantages:

1. RF-excited laser system ensures stable performance.
2. Windows CE system facilitates a remote upgrade.
3. Ultrapure, CW, fractional laser output modes extends treatment range.
4. Patent adjust with spot size 80 to 2000μm adjustable provides a full spectrum of ablation.
5. Max. 30W power output, Min. 50μm spot size enables 4mm penetration to release treatment painlessly and complications.
6. Max 3cm*3cm, Min. 0.25cm*0.25cm treatment area provides a fast and precise treatment.



YILIYA-10600AL Specification

Laser Type	RF-excited CO2 laser	Wavelength	10600nm
Beam Delivery	7-joint arm	Maximum Output Power	30W/20W/10W(optional)
Optical Beam Quality	TEM	Spot Size	80um-2000um
Power of the Aiming Beam	≤5mW	Aiming Beam	635nm
Scanning Mode	Randomized Scanning	Laser Operating Mode	Ultra Pluse, CW, Fractional
Cooling	Air Cooling	Pulse Energy	10mj-200mj(stepping:2mj)
Spot Pattern	Triangle/Square/Rectangle/ Rhombus/Round	Pulse Interval	2ms-100ms(stepping:1ms)
Scan Area	5*5mm, 2.5*2.5mm, 1.25*1.25mm 30*30mm, 20*20mm, 10*10mm	Dimensions(before  packaged)	650mm*340mm*760mm
Spot Density	36spots/cm², 144spots/cm², 576spots/cm²	Dimensions(After Packaged)	760mm*455mm*975mm
Power Supply	AC220V  50HZ / AC110V 60HZ
