Indoor PH10 mm SMD 3 in 1 2000 nits Brightness Silan Led Screen Rental
Descrpition:
1. High definition rental led display.
2. rental led display with silan, nichia, cree lamp, linsn controller, etc.
3. Professional rental led display.
4. Vivid view rental led display.
Applications:
Wide Application Field: advertising LED display, Stadium perimeter LED display , Mobile led display for mobile media , shopping mall LED display for logo showing , bank & stock exchange LED display for rates showing , train & bus station , airport , telecommunication LED screen system for information showing and instruction , Stage performances and so on
Specifications:
|
Pixel pitch |
PH10 |
||
|
Model No |
|||
|
Module Parameters |
Pixel pitch |
10 mm |
|
|
Pixel Density |
10000pixels/m2 |
||
|
LED Shape |
SMD 3 in 1 |
||
|
LED Configuration |
1R1G1B |
||
|
Module Resolution |
16*16 pixel |
||
|
Module Size |
160*160mm |
||
|
Drive Mode |
1/8 |
||
|
Cabinet Parameters |
Cabinet Resoltuion |
128*96 |
|
|
Cabinet Size |
1280*960*135mm |
||
|
Module Quantity |
48pcs |
||
|
Cabinet Weight |
58kg |
||
|
Display Parameters |
Optical |
Brightness |
≥ 1100cd/m2 |
|
Brightness adjustment |
Brightness of R, G, B adjustable by the software 256 grades |
||
|
Viewing angle |
H/V 120/120 |
||
|
Best Viewing Distance |
12m |
||
|
Display Color |
16.7 million |
||
|
Grey Scale |
10bits/1024levels |
||
|
Power |
Max power consumption |
700W/M2 |
|
|
Ave power consumption |
280W/M2 |
||
|
Working Voltage |
AC 220V ± 10% |
||
|
Control system |
Frame Frequency |
60--85HZ |
|
|
Refresh Rate |
360--1000HZ |
||
|
Color Temperature |
5000--9300K |
||
|
Signal Input |
Composite , S-video, Component, VGA, DVI, HDMI, SDI, HD_SDI, etc |
||
|
Controlling system |
PCTV non-linear editting card+DVI display card+main controller card+optical fiber transmission (Optional) |
||
|
Controlling Distance |
By CAT5 Cable:100M, Multi-Mode fiber: 500M, Single-Mode fiber : 10 KM |
||
|
Reliability |
Working Temperature |
﹣ 20 ﹢ 65 ℃ |
