Certification:CE & ROHS
PH4 mm 2000 Nits Indoor Shopping Mall Full Color Led Signs For Logo Showing
Descrition:
1. High definition led sign.
2. led sign with silan, nichia, cree lamp, linsn controller, etc.
3. Professional led sign equipments.
4. Vivid view led sign.
Specifications:
|
Pixel pitch |
PH4 |
||
|
Model No |
|||
|
Module Parameters |
Pixel pitch |
4 mm |
|
|
Pixel Density |
62500pixels/m2 |
||
|
LED Shape |
SMD 3 in 1 |
||
|
LED Configuration |
1R1G1B |
||
|
Module Resolution |
32*32 pixel |
||
|
Module Size |
128*128mm |
||
|
Drive Mode |
1/8 |
||
|
Cabinet Parameters |
Cabinet Resoltuion |
224*352 |
|
|
Cabinet Size |
896*1408*150mm |
||
|
Module Quantity |
77pcs |
||
|
Cabinet Weight |
56kg |
||
|
Display Parameters |
Optical |
Brightness |
≥ 3000cd/m2 |
|
Brightness adjustment |
Brightness of R, G, B adjustable by the software 256 grades |
||
|
Viewing angle |
H/V 160/120 |
||
|
Best Viewing Distance |
4m |
||
|
Display Color |
16.7 million |
||
|
Grey Scale |
10bits/1024levels |
||
|
Power |
Max power consumption |
1200W/M2 |
|
|
Ave power consumption |
600W/M2 |
||
|
Working Voltage |
110V-220V |
||
|
Control system |
Frame Frequency |
60--85HZ |
|
|
Refresh Rate |
360--1000HZ |
||
|
Color Temperature |
5000--9300K |
||
|
Signal Input |
Composite , S-video, Component, VGA, DVI, HDMI, SDI, HD_SDI, etc |
||
|
Controlling system |
PCTV non-linear editting card+DVI display card+main controller card+optical fiber transmission (Optional) |
||
|
Controlling Distance |
By CAT5 Cable:100M, Multi-Mode fiber: 500M, Single-Mode fiber : 10 KM |
||
|
Reliability |
Working Temperature |
﹣ 20 ﹢ 65 ℃ |
|
|
Working Humidity |
10-90%RH |
||
|
Life Span |
100, 000 Hours |
||
|
MTBF (Ave No Faliure Time) |
5000 Hours |
||
|
Pixel failing Rate |
0.01% |
