RoHS With 3M Adhesive Backlit Membrane Switch Corrosion Resistance IML
Description:
1) Membrane Switch with windows
2) Touch feeling keys with embossing
3) Silk Screen Printing
4) Over 1 million life cycles
5) Metal dome or silicone keypad is also available.
Commercial terms:
MOQ: 100pcs
Payment Terms: T/T or L/C
Mold Charge: 100% in Advance
Sample Time: 9-10 days after drawing approval.
Lead Time for production: 15-22 days after sample approval
Applications:
Our membrane switches are widely used in:
Medical Equipment Telecommunications apparatus Telephone systems Household appliances Security systems Industrial controlsSpecifications:
|
wire lead resistance: |
＜1Ω/CM |
Life time: |
>1 Million times |
|
rated current: |
25-100mA,0～30V DC |
Operation Temperature: |
-40℃～70℃ |
|
Rated Voltage: |
＜50V, DC |
Operation Humidity: |
at40℃,＜98%RH |
|
Insulation resistance: |
＜100MΩ,250V DC |
Dome springback time: |
＜5 msec |
|
Switch travel: |
Flat Type 0.05-0.3mm |
Base Material voltage withstand: |
1500 V DC |
|
tactile type:0.3-1.5mm |
Tail flexiblility: |
any angle within 180 degree |
Company Advantage:
Top managers are experienced in the same field for many years. Professional staff and workers. Strong R&D cabability Quick Delivery Competitive price Two factories are available for large ordersExpert sales team and good customer service.
