Ductile Iron Cast Water Submersible Pump Housing JIS , BS , DIN

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ZMPC		Place of Origin	China
Model Number	cast bronze spare parts.

Product Description

Delivery Time:Sample sent to customer by air. Large quantity products by sea from Shanghai. Production time 20-30 days
Certification:ISO9001,BV

Ductile iron cast water submersible pump housing JIS , BS , DIN

Quick details:

Place of Origin : Jiangsu,China (Mainland)
Theory: Submersible pump
material cast iron
Machinery: Full machinery service provided
Application Submersible,Submersible pump
discription pump housing/motor frame
2. Packaging and Delivery
Packaging Usually with Wooden case As per customers\' requirements
Delivery Detail According to your quantity
3. Material:Cast iron
4. Dimension:Customized
5. Application:submersible pump
6. ISO certificated

Diversion shell:

Diversion shell is an important energy conversion device, the hydraulic losses in diversion shell accounts for about 40 to 50% of the pump. The diversion pump collected liquid from the impeller, and transported it to the next stage impeller inlet or pump outlet; convert the pressure function into velocity energy; try to eliminate the liquid pre-swirl in the next one impeller inlet.

1. Our Product:

1.Used for:Various casting and machining products

2. Material: Iron, carbon steel, stainless steel, alloy steel, high manganese steel, heat resistant steel, copper alloy, aluminum alloy, Hastelloy alloy etc.

3.Tolerance: 0.001mm after machining

4. Tooling design and fabrication available

5.Machining: Turning, Milling, Drilling, Grinding, Welding, Tooling, Broaching, Wire EDM etc.

6: Surface treatment: Powder coating ,Painting ,Shot blasting, Polishing ,Electrical galvanizing, Chemical galvanizing, Chrome plating , Nickel plating, Passivation etc.

7. Standard: AISI, ASTM, JIS, BS, DIN, ISO, EN, GB.

2. Service offer:

Drawing:

We will translate your original drawing; make manufacturing procedure plan, offer professional suggestions on the design if needed.

Engineering design software: Solidworks, AutoCAD.PROE

DWG .DXF .IGS ,jpg formats are acceptable.

Quality control:

We have full set of quality control system to guarantee best product quality. Depends on the products, we make different item testing plan, different manufacturing procedure and provide certified lab mechanical testing.

We have the chemical analyzing chamber to analyze the component content of the material after entrance to the factory, on melting and after casting to promise the chemical component content.

After getting the drawing , we first put into the software anycasting to analyze and build the mold and the feed system.

We have UT, RT, MT equipment to test the product, promising the quality of the casting, both internal and surface.

Also we can do the strength test for mechanical stress.

Any way we can supply our costumer the qualified product, as promised.

We have our Q.A. Team to promise the quality and can supply the quality certificate. and also the third part intervention for QC is also acceptable.

Samples:

If it is only samples available, we can draw the drawings for you.

3. Edges

Edges in Quality	We have years of experience and most of our clients are satisfied with our products.
Edges in Cost	The price of is reasonable and more competitive.
