C1000 Handheld COFDM Receiver 1080p full HD for Patrol
Introduction:
1, New design portable COFDM AV receiver (with sweep-frequency function), has advantages of small size and lightweights
2, Adapts multi-carrier diversity reception technology
3, Supports high-speed mobile transmission and NLOS reception
4,Uses 10.1\" TFT high-resolution full-touch control and display and provides concise control experience and perfect image, while adding spectrum scan function that can quick to search the current area caused by the same frequency interference from surrounding equipment which can provide reference quick data for installation
5,Widely used in security, fire, broadcasting and TV, emergency communications and other industries
Features:
COFDM modulation and H.264 decoding
Multi-carrier dual antenna diversity reception
Multi-band sweep function (English menu)
10.1\" touchscreen control
Built-in battery, small size, lightweight and high reliability
Technical Parameters:
|
Item |
Description |
|
Modulation Type |
COFDM |
|
Working Frequency |
46-860MHz; per 0.5M adjustable |
|
RF Bandwidth |
2/3/4/5/6/7/8MHz(optional) |
|
Sensitivity |
-106dBm |
|
Video Output |
HDMI display,External Display Screen: AV Output |
|
Video Compression |
MPEG-2, H.264 |
|
Audio Output |
3.5 mm headsets |
|
Forward Error Correction |
1/2,2/3,3/4,5/6,7/8 |
|
Parameter Control Method |
Adjustable Digital LED Control Panel |
|
USB |
External Memory: U Flash Disk |
|
Encryption Method |
128 - bit AES (can set user’s password) |
|
Antenna Interface |
N Female Head*2 |
|
Display Screen Size |
10.1 Inches |
|
Working Voltage |
DC12V |
|
Working Current |
1Ah to 1.5Ah |
|
Working Temperature |
-10~70℃ |
|
Dimensions |
300*200*30(mm) |
|
Weight |
2(Kg) |
