Certification:CE/FCC/ROHS
1920 x 1080 32 inch closed Sunlight readableLCD Display 1500nits 118W With Automatic Light
1500nits High Brightness monitor display of 32 inch with high contrast 3000:1 high performance LCD open frame touch monitor with VGA HDMI, AV , Video input ; IR touch screen LCD
vesa mounting easily used for Digital Signage , Gaming , Automatic equipments, Outdoor Advertising , vending embedded system,Kiosks application etc.
Quick Details:
Model: AXD-32OPN1P3-VH4
Screen Size:31.5’’
Screen format: 16:9
Display Resolution(pixel):1920x1080
Contrast Ratio:3000:1
Brightness:1500cd/m^2
Storage temperature : -20℃~60℃
Input signal: VGA DVI; HDMI; AV; Video;USB; S-video, etc
Power Input: AC100~240 V/DC 12V
Product status: Stock
Features and Advantages
1. High Resolution with high contract LCD in stable supply
2. industrial control board supports the displays
3. 178/178 wide viewing angle with high performance
4. VGA HDMI ,AV ,Video, YPbPr etc interfaces
5. Integrated solution for touch screen and LCD display; good performance and easy assembling.
6. Interface both for USB and RS232 is available. No further hardware is needed for the convenience of NBSP users.
7. Higher sensitivity and faster response
8. Long durability; 1500nits high brightness LCD panels for this industrial monitor grade
9. Multi-options for assembling, including vertical, horizontal support. You may assemble it in VESA standard solution or in your own design.
10. We also provide the service of producing the product in users’ own design.
|
Display Specifications |
|
|
Display |
32\" Color TFT high brightness monitor |
|
Model Name |
AXD-32OPN1P3-VH4 |
|
Active Display Area (mm) |
698.4 (H)x392.85(V) |
|
Pixel Pitch (mm) |
0.363(H)x0.363(V) |
|
Resolution (Pixel) |
WSXGA (1920X1080) |
|
Brightness (CD/m^2) |
1500cd/m^2 |
|
Contrast Ratio |
3000:1 |
|
Viewing Angle (CR >=10) |
178/178 |
|
Power consumption |
118 W typical, normal operation |
|
Touch Screen |
Resistive RS232/USB(Optional) |
|
OSD Control |
On the back side |
|
I/O Connectors |
1x12v,1XVGA,DVI-D(Optional) |
|
Power Input Touch Screen options |
220v IR Touch panel Options |
|
Mechanical Specifications |
|
|
Construction |
Steel metal housing ,black colors |
|
Dimensions |
811.0x 450.0x 75.2(mm) |
|
Mounting |
Embedded , Vesa mounting |
|
Power source |
AC 100~240V/ 12V DC |
|
Environment Specifications |
|
|
Operating Temperature |
0~60℃ |
|
Storage Temperature |
-20~60℃ |
|
Rating |
Facilitate installation of the demolition,solid portfolio |
|
Ordering Information |
32” Closed IR touch LCD HD with 1500nits brightness monitors |
Packaging & Delivery
|
Packing details |
1x 32 inch Sunlight Readable LCD display; Packed in 2 pieces/carton with protection foam Optional accessories: 1xVGA, 1x Power supply cable adapter |
|
Delivery terms |
7- working days for stock products after receiving payments; 15 working days for order production |
