IE1 0.37KW 6 Pole Three Phase Asynchronous Squirrel Cage Motor 40HZ - 60HZ
|
Ambient |
|
|
Temperature range: |
-20~40℃ |
|
Ambient humidity: |
90%less than relative humidity |
|
Altitude: |
less than 1000m above sea level |
|
Ambient condition: |
no causticity gas, no dust, no heavy mental pollution, no flame, no salt crystallization |
|
Supply power: |
|
|
Voltage variable |
±5% |
|
frequency variable |
±2% Combine voltage and frequency variable : ±5% |
|
Standard Feature: |
|
|
Standard |
IEC /DIN |
|
Efficiency Level |
IE1 |
|
Phase |
Three-phase |
|
Frame Size |
H80~355 cast iron frame |
|
Protect Feature |
Totally Enclosed |
|
Output Range |
0.37~250KW |
|
Voltage |
380V |
|
Frequency |
40-60HZ (50-60HZ constant power) |
|
Pole |
6 |
|
Protection Class |
IP54/IP55 |
|
Insulation |
F/B |
|
Mounting |
IMB3 /IMB35/IMB5 or on your request |
|
Cooling |
IC411 |
|
Duty |
S1 |
|
Connection |
” Y\" type for 3kW and downwards, \"D\" type for 4kW and upwards |
|
Thermometry |
Optional |
|
Certification |
CCC, CE,ISO9001 |
|
Special motors can be designed according to customers\' requirements |
Meaning of type code
Technical Specification (6 pole/1000r/min 380V/50HZ )
|
Motor Type |
Rated Power |
Current |
Rated Speed |
Rated Torque |
Power Factor |
Efficiency |
Locked Current |
Locked Torque |
Maximum Torque |
Weight |
||
|
Rated Current |
Rated Torque |
Rated Torque |
||||||||||
|
kW |
HP |
380V InA |
400V IoA |
r/min |
N.m |
cosΦ |
η% |
Ist/IN |
Tst/TN |
TM/TN |
kg |
|
|
YP2-80M1-6 |
0.37 |
0.5 |
1 |
1 |
885 |
3.5 |
0.70 |
62.0 |
4.7 |
1.9 |
2.0 |
15 |
|
YP2-80M2-6 |
0.55 |
0.75 |
2 |
2 |
885 |
5.3 |
0.72 |
65.0 |
4.7 |
1.9 |
2.1 |
16 |
|
YP2-90S-6 |
0.75 |
1 |
2 |
2 |
915 |
7.2 |
0.72 |
