Certification:ISO9001
1. Name: Computer to plate prepress printing machine,CTP quality products structure like CRON,SCREEN
2. Application: Prepress Printing Area
3. Feature: Strict filter test of laser ,Independent vacuum structure, special “V”
Groove guide rail.
Description:
DOIE company is a professional manufacturer of computer to plate (CTP). UV-CTP 32 channels is UV type of DOIE CTP products which uses the most advanced and stable technology to achieve excellent quality products.
32channels has 32 pics laser diodes in machine, make up the most significant part of machine,The 32 laser diodes is 405nm type.
The speed of DOIE machine is higher compared with AMSKY,according to various plate size,different speed of machine can meet different demand of customer.(newspaper area,printing hourse,printing center)
Unique and professional design of drum with 3 independent vacuum space efficiently to avoid plate flying off.
Specifications:
|
Model |
X-0322U |
|
Light Channels |
32 |
|
Output Speed(P/h) |
17 |
|
P size:1030mm×800mm |
|
|
29 |
|
|
P size:510mm×400mm |
|
|
Light Source |
405 nm Laser Diode |
|
Output Resolution (dpi) |
2400 |
|
Dot Reproduction |
1%～99% |
|
Register Accuracy (mm) |
＜0.01 |
|
Plate Size (mm) |
Max. 1160×940；Min. 450×320 |
|
Suitable Plates |
Various UV-CTP(CTcP) plates |
|
Plate Thickness (mm) |
0.15~0.30 |
|
Plate Loading and Unloading |
Loading:Automation(Standard Set) Unloading:Automation Vacuum Fixation |
|
Plate Position Accuracy (mm) |
0.2 |
|
Plate Balance |
Automatic Balance |
|
Data Interface |
USB,1000Mbit/s |
|
Ambient |
Temperature 25℃±3℃ Humidity 20~80%(Non-condensing) |
|
Machine Dimension (mm) |
L2200×W1100×H1050 |
|
Net Weight (kg) |
1500 |
|
Power Supply |
≤6KW/220V±5%,50/60Hz |
Applications:
One integral digital press workflow consisted of auto loader,CTP machine,bridge,processor,stacker.These parts together reduce labor cost and maximize improve productivity.CTcP machine can use normal CTcP/UV plate on market, it allows customer choose plate by themselves,this is big advantage of DOIE machine.Most CtP manufacturers like cron and amsky bound with their own cooperation plate company.
Competitive Advantage:
1: Precise guiderail chassis. Manual entire scrape.
The chassis is HT300 inblock cast, guiderail and chassis became in one, the high mechanical strength, the high heat stability, less possibility of deformation. The guiderail precision could achieve 1-3μm/m,effectively ensure printing precision. Scraping guiderail is made by cast-iron, the surface has one thin oil slick, play an lubricant, protective role; Using import soft guide pairs and precise grinder guiderail technology, make optical platform move has little wear; the moving of platform has better smooth, precision.2. Independent vacuum structure, effectively absorb various plates.
By using the three-cavity technology, the drum could effectively absorb various plates, avoid the plate. According to different size of plate, adjust absorptive power, could achieve best printing effect. Using negative pressure checking before printing, avoid the plate flying. Using n
