1.Name: CTcP computer to plate high exposure precision machine with 64channels 405nm laser
2. Application: Prepress Printing Area
3. Feature: Perfect and stable laser diodes from JAPAN
Feeding fan design for loading system
Unique and workable design of temperature control
Description: CTcP plate making machine upgrade technology for loading system,temperature control system etc. After durable test, laser barely broken one year ,customer don’t need change new laser after warranty. Meanwhile, motor structure is very simple to control and maintain. Virtually DOIE machine help customers saving money all the time.
Specifications:
|
Model |
X-0642U |
|
Light Channels |
64 |
|
Output Speed(P/h) |
29 |
|
P size:1030mm×800mm |
|
|
47 |
|
|
P size:510mm×400mm |
|
|
Light Source |
405 nm Laser Diode |
|
Output Resolution (dpi) |
2400 |
|
Plate Size (mm) |
Max. 1160×940；Min. 450×320 |
|
Plate Loading and Unloading |
Loading:Automation(Standard Set) Unloading:Automation Vacuum Fixation |
|
Dot Reproduction |
1%～99% |
|
Suitable Plates |
Various UV-CTP(CTcP) plates |
|
Plate Thickness (mm) |
0.15~0.30 |
|
Register Accuracy (mm) |
＜0.01 |
|
Plate Position Accuracy (mm) |
0.2 |
|
Plate Balance |
Automatic Balance |
|
Data Interface |
USB,1000Mbit/s |
|
Ambient |
Temperature 25℃±3℃ Humidity 20~80%(Non-condensing) |
|
Machine Dimension (mm) |
L2200×W1100×H1050 |
|
Net Weight (kg) |
1500 |
|
Power Supply |
≤6KW/220V±5%,50/60Hz |
Applications: DOIE CTcP machine is digital integral printing workflow,fittable to printing house and output center. DOIE always provide customer timly aftersales and competitive price.Customer can also choose their own like plate to decrease costs.
Competitive Advantage:
1. Precise guiderail chassis. Manual entire scrape.
The chassis is HT300 inblock cast, guiderail and chassis became in one, the high mechanical strength, the high heat stability, less possibility of deformation. The guiderail precision could achieve 1-3μm/m,effectively ensure printing precision. Scraping guiderail is made by cast-iron, the surface has one thin oil slick, play an lubricant, protective role; Using import soft guide pairs and precise grinder guiderail technology, make optical platform move has little wear; the moving of platform has better smooth, precision.2. Independent vacuum structure, effectively absorb various plates.
By using the three-cavity technology, the drum could effectively absorb various plates, avoid the plate. According to different size of plate, adjust absorptive power, could achieve best printing effect. Using negative pressure checking before printing, avoid the plate flying. Using negative pressure checking in printing, avoid the plate flying. Using negative pressure and prevent air leakage technology.3. High precision side-guide technology, improve printing repeatability precision.
Fusing advanced plate-edge checking technology and side-guide technology, improving the printing repeatability precision. High precision side-guide technology, making the equipment running more stable. According to the requirement, increase dynamic b
