Wall and Pole Mountable 32Port FTTH CATV Outdoor Distribution Box for 1*32 PLC Splitter

Delivery Time:3-5 days
Certification:ROHS, SGS

Wall and pole mountable 32Port FTTH CATV outdoor distribution box for 1*32 PLC Splitter

Quick Detail:

Name: PLC Distribution Box Up to 32 FTTH drops Indoor and outdoor, waterproof type Material: Cold rolled steel

Wall and pole mountable

Can accommodate1X32 PLC splitter

Description:

Applicable in FTTH project

Suitable for corridor, basement, room and building\'s outer walls application

Features:

High quality cold rolled steel body, electrostatic spraying with water proof powder High quality water proof lock, wall mounted cabinet Suitable for 72pcs of SC, FC, ST adapters, easy to installation and maintenance Support branch connection styles Operating temperature:-30°C~+55°C,storage temperature: -40°C~+60°C With access to 2pcs of 12 cores fiber optic cables and up to 64 pcs of customer cables Suitable for multi fiber optic cable access as well

Applications:

CATV Networks Data communications Networks Local Area Networks Widely used in FTTH access network. Telecommunication Networks

Specification:

Item	FDB-0132
Dimenstion (mm)	H600xW570xD190
Cable diameter (mm)	Ф10～Ф14
Cable ports	2 holes
Max capacity of splice tray	24 (single fiber)
Max quantity of splice tray	3
Max capacity of main backbone cable	12 (single fiber)

Shipping:

Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.) Airport to Airport: by air Seaport to Seaport: by sea (our location Shenzhen is a seaport.)
