Help CenterRed Glue / Solder Past Dispensing Pressure Vessel 5L Stainless Steel Pressure Container
Related Products
-
Adhesive / Epoxy / Instant Glue Dispensing Pressure Vessel 10LNegotiableMOQ: 1 Piece -
Conductive Adhesive / Silicon 10L Stainless Steel Pressure TankNegotiableMOQ: 1 Piece
-
Instant Glue Dispensing Pressure Vessel , 50L Stainless Steel Pressure TankNegotiableMOQ: 1 Piece
-
20L Dispensing Stainless Steel Pressure Vessel For AB Glue / EpoxyNegotiableMOQ: 1
-
High Precision 2L Dispensing Pressure Vessel For Epoxy Adhesive / SealantNegotiableMOQ: 1 Piece
Certification:CE/ROHS
Specifications
Pressure tank for glue dispensing machine:
1. high quality with factory price.
2. The capacity can be custom made as your request.
3. Widely use in contain may kind of fluid ,such as:
UV glue; AB glue; EPOXY; white glue; conductive adhesive; SILICON; epoxy; instant glue; silver glue; red glue
Applicable fluid
Silica gel, EMI conductive adhesive, UV glue, AB glue, fast
dry glue, epoxy adhesive, sealant, hot glue, grease, silver
glue, red glue, solder paste, cooling paste, prevent solder
paste, transparent lacquer, screw fixation agent, etc.
Main use
1) Processing with bonding, infusion, coating, sealing, filling,
dropping, linear/ arc/ round gluing etc.
2) Dispense in point, line, surface, arc, circle and irregular
curve, and triaxial linkage function is available.
Volume | Weight(kg) | OD(mm) | ID(mm) | OUT Deepth(mm) | Inner Deepth(mm) | Thick(mm) | Cover dimension(mm) | Max Pressure (bar) | material |
1 L | 3.5 | 108 | 102 | 140 | 125 | 3 | 12 | 7 | stainless steel |
2 L | 4.5 | 133 | 127 | 180 | 165 | 3 | 12 | 8 | stainless steel |
3 L | 6 | 133 | 127 | 255 | 240 | 3 | 12 | 8 | stainless steel |
4 L | 7 | 159 | 152 | 245 | 230 | 3.5 | 12 | 8 | stainless steel |
5 L | 8 | 159 | 152 | 300 | 285 | 3.5 | 12 | 8 | stainless steel |
8 L | 16 | 219 | 210 | 250 | 235 | 4.5 | 14 | 8 | stainless steel |
10 L | 17 | 219 | 210 | 310 | 290 | 4.5 | 14 | 8 | stainless steel |
15 L | 19 | 219 | 210 | 450 | 435 | 4.5 | 14 | 8 | stainless steel |
20 L | 30 | 273 | 262 | 400 | 385 | 5.5 | 14 | 8 | stainless steel |
25 L | 33 | 273 | 262 | 490 | 470 | 5.5 | 14 | 8 | stainless steel |
30 L | 43 | 325 | 314 | 420 | 400 | 5.5 | 14 | 8 | stainless steel |
40 L | 46 | 325 | 314 | 540 | 520 | 5.5 | 14 | 8 | stainless steel |
60 L | 60 | 376 | 365 | 600 | 580 | 5.5 | 16 | 8 | stainless steel |
80 L | 89 | 425 | 410 | 620 | 600 | 7.5 | 16 | 8 | stainless steel |
