Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Support any format of video, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION
2. ≤1mm surface level up, smooth video
3. Perfect quality and stability, 24/7 running
4. Powerful supply for big order.
5. Longer lifespan. (more than 100,000 hours life)
6. Modular design, flexible shape for big area
SMD 3 in 1 P5 HD Indoor Full Color LED Display for Advertising 40000 dots/m2
Description:
1. With good lightening accordance and no mosaic.
2. Can play different formats of image files, flash, video signal from TV, video and other equipments.
3. Different video frequency can be changed freely at the same time, and the image can be enlarged and
shrinked.
4. High brightness, and can be adjustable, meets the needs of customer\'s requirements.
Uses real pixels rather than virtual pixels, better viewing effect .
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,
shopping malls, railways, airports, harbors, etc;
Specifications:
1. Indoor LED Display Technical Parameter
|
Model No. |
NS-IR-SD-P5 |
|
Pixel Pitch |
5mm |
|
Module Size |
160mm×160mm |
|
Module Resolution(Pixel) |
32dots×32dots |
|
Pixel Density |
40000dots/m2 |
|
LED Type |
SMD 3 in 1 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/8 Duty Constant Current |
|
Cabinet Size |
800×640×135mm |
|
Cabinet Resolution |
160dots×128dots |
|
Brightness |
≥2000cd/m2 |
|
Contrast |
≥2000:1 |
|
Viewing Angle |
140°(Horiztal )/45°(Vertical ) |
|
Best Viewing Distance |
≥5 m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
2000 W/m2 |
|
Average Power Consumption |
650 W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85HZ |
|
Refresh Frenquency |
240-1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
Static:-40°C~+85°C Working:-20°C~+60°C |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
|
Video Signal Input |
RF,S-Video,RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite |
|
Video Signal Output |
RF, S-VideoR, GB, RGBHV, YUV, YC etc. |
|
Graphics Card |
DVI Graphics Card |
|
Control Distance |
UTP CAT5E:100m Multi-mode Fiber:500m Single-mode Fiber:10km |
|
Control Syst |
