High Precision Custom Adhesive Dispensing Machine 10-100PSI / 1-80PSI

Delivery Time:5 working days after received your payment
Certification:CE/ROHS

Adhesive Dispensing Machine/vs-983 high precision Automatic Glue Dispenser

Specifications:

983 dispensing glue gun	Dimensions	: 235mmx225mmx60mm
Spit mode:	16 kinds of free-setting mode, time display with spit
Power supply	: AC 220V ± 10% / 50Hz AC 110V ± 10% / 60Hz (can be internal conversion)
Internal voltage	: 12VDC/24VDC
type	vs 983
Input pressure / output pressure	10-100PSI / 1-80PSI
Air source	Maximum 0.99MPa (clean dry air without lubrication)
Out pressure adjustment range	0.05MPa - 0.99MPa
Clock out time	00.01-99 .99 S
Artificial time out	Sustainable spit coating, crossed

Description:

1, controlled by microcomputer making the dispensing volume and time more precise.
2, Easy and convenient to operate, matched with manual or pedal switch, enable to dispense with certain volume in fixed time.
3, Four modes available,manual,automatic,semi-auto,pedal control.
4, Perfect appearance by design, smart volume for saving space.
5, Kinds of dispensing nozzles for choosing.

6, one set include: one PCS dispensing machine, one PCS foot switch, one glue tank, one PCS nozzle, one PCS adaptor

.

Instruction and installation

1.Installation

2.Setting the way

Attention and maintenance

1, Air pressure cant be more than 7bar(10psi), working air pressure cant be more than5.5bar (78psi), if the working air pressurer is more than 4 bar, pls use the original partsfrom the manufacter.

2, The liquid material must be stired evenly before putting to the cylinger needle. It will be better if the liquid material can be stored at the stable temperature of 5 degree centigradeto make sure there is no big change in the density of the liquid material. If the density ofthe liquid is so high, ( it means the liquid is so viscous, it may be hard to spit out). If theliquid need to be diluted, pls compliant to the instruction of the liquid material manufacture.

3, Don’t sharply increase the Vacuum, otherwise, the liquid will be pulled in the catheterby the vacuum. The qty of the vacuum pump back rely on the air pressure level, workingcycle, qty of the liquid to spit. If the qty of the vacuum is too much, the piston will beoverset, disturbing the normal work

4, Avoid to overset the liquid cylinder, otherwise, the liquid will flow to the air cylinderto destroy the internal aprt.

5, Pls clear the stuff left in the cylinder needel when needed. Otherwise the stuff willbecome hard, then disturbing the vacuum pumpback and stop the cylinder needle.

6, After using the machine, the cylinder needle need to be cleaned every time, otherwise,it is difficult to unload the needle when the liquid becomes hard. Normally, it is easy toremove the liquid from the inside of the cylinder needle, just dipping the parts in the handwater for 5~10minutes, all the part will be cleaned.

7, Pls disposal the used needle and cylinder needle at appropriate place to avoide somei nappropriate liquid pollution

Advantage:

(1) 10-year esd producst Manufacture Experience

(2) Quick and Safe Delivery

(3) Professional Service Team

(4) 24 hours On Line Customer Service

(5) OEM and ODM Services offered.

(6) Distribution Channel in all over the world
