P16 Flexible LED Screen Soft LED Display Full Color For Night Club
Quick Detail:
1. ≤1mm surface level up, smooth video
2. Long lifespan up to 100,000 hours
3. High brightness: >6000cd/㎡
4. IP65 Ruggedness, all-weather qualified
5. Support any format of video, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION
6. Perfect quality and stability, 24/7 running
Description:
1. It can be curved into different shape to fit convex or concave wall or rugged wall or building, also it can
be shaped into column to wrap pillars for animation decoration.
2. We make best design with high cost- efficiency according to the actual needs of our customers and we
can offer OEM service as well.
3. Easy to maintain, High resolution, Good contract, Less Weight, easy to install. Widely used as the
information billboard in Airport, Railway station, and big shopping mall, concert and ect.
4. The brightness of indoor LED signs is adjustable so as to ensure different environment.
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,
shopping malls, railways, airports, harbors, etc;
Specifications:
1. Outdoor LED Display Technical Parameter
|
Model No. |
NS-OR-DD-P16 |
|
Pixel Pitch |
16mm |
|
Module Size |
256mm×256mm |
|
Module Resolution(dots) |
16*16 |
|
Panel Size |
1024mm×768mm |
|
Panel Resolution(dots) |
64×48 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(dots/m2) |
3906 |
|
Brightness(cd/m2) |
≥ 8000 |
|
Best Viewing Distance(m) |
15-300 |
|
Max. Power Consumption(W/m2) |
1000 |
|
Drive Mode |
Static |
|
Wavelength |
R 620-625 G 520-525 B 470-475 |
|
Viewing Angle |
110°(H)/45°(V) |
|
Operating Temperature |
–20~60°C |
|
Video Frame Rate(Hz) |
≥60HZ |
|
Display Refresh Rate(Hz) |
≥300HZ |
|
Grey Level(colors) |
16.7million |
|
Life Span |
≥100,000 hours |
|
Working Voltage |
220V±15% OR 110V±15% |
|
Video Signal Input |
RF,S-Video, RGB,RGBHV,YUV,YC,COMPOSITION |
|
Control System |
LINSN OR DB-STAR |
2. Outdoor LED Display Module
|
Module Size (W*H) |
256mm*256mm |
Pixel Configuration |
1R1G1B |
|
Pixel Pitch |
16mm |
Resolution (W*H) |
16 dots*16 dots |
|
Pixel Density |
3906 dots/㎡ |
LED Type |
3mm Oval Lamp |
3. Outdoor LED Display Cabinet
|
Cabinet Size (W*H) |
1024mm*768mm |
Module Qty |
12 pcs |
|
Cabinet Resolution (W*H) |
96 dots*64 dots |
Cabinet Pixel |
6144 |
|
Weight |
