Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Audio & Video Cable > High Speed Precision 3 Axis Glue Dispensing Machine AC110 220V 300W
High Speed Precision 3 Axis Glue Dispensing Machine AC110 220V 300W
US$ 6350 - 6350
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
VISION
Place of Origin:
China
Model Number:
VS-400
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Professional Silicone Sealant Dispensing Robot With Micro - Step Precision MotorUS$ 6350 - 6350MOQ: 1 Set -
High Performance Accuracy Robotic Glue Dispenser Machine Systems With Small FootprintUS$ 6350 - 6350MOQ: 1 Piece
-
Desktop Epoxy Adhesive Dispensing Robot Systems With Ce ListedUS$ 6350 - 6350MOQ: 1 Meter
-
Conductive Adhesive / AB Glue / Epoxy Dispensing Machine For PCB Board / SpeakerUS$ 6350 - 6350MOQ: 1 Piece
-
OEM Precision CNC Instrument Glue Dispensing Robot With RS232 InterfaceUS$ 6350 - 6350MOQ: 1 Piece
Brand Name
VISION
Place of Origin
China
Model Number
VS-400
Delivery Time:7 working days after received your payment
Certification:ROHSSGS
OEM VS-400 dispensing robot/ glue robot & dispenser
Certification:ROHSSGS
OEM VS-400 dispensing robot/ glue robot & dispenser
Specifications:
1. Man-machine interface, easy to operate.
2. 3 axis movement
3. Simple easy high-speed precision operation
4. 1 year warranty
| model | VS-400 |
| Working Range X/Y/Z (mm): | 400/400/100 |
| Load Y-AXIS / Z-AXIS: | 10/ 5kgs |
| X&Y / Z ( mm/sec ): | 0.1-800/5000 |
| Resolution: | 0.001 mm/Axis |
| Repetitive Positioning Accuracy: | 0.01 mm/ Axis |
| Program Capacity: | At least 100 groups, each group 4000 points |
| Data Storage Type: | CF Card |
| Program Display: | Teach Pendant LCD |
| Motor System: | Micro-step precision motor |
| Control Method: | PTP & CP |
| Interpolation Function: | 3 axis ( 3D stereo space arbitrary paths can) |
| Programming Method: | Teaching box / PC |
| I/O Signals Port: | 8 / 8 Outputs Inputs |
| External Control Interface: | RS232 |
| Power Supply: | AC110 220V 300W |
| Working Temperature: | 10 - 40 C |
| Working Relative Humidity: | 20 - 90% no condensation |
| Dimensions (WxDxH mm): | 480X600X600 |
| Robot Weight (kg): | 40kgs |
Features
1. English touch panel, easy operation.
2. Glue Dispenser Function: Drawing point, line, surface, arc, circle, irregular curve continuous complement and triaxial linkage.
3. Can set glue size, glue speed, dispensing time, stopping glue time. Stable glue exudation without glue leaking and dripping.
4. The dispensing head set the micro touch switch, convenient operation; no air pressure, power can work.
Competitive Advantage:
(1) 6-year dispensing robot Manufacture Experience
(2) Quick and Safe Delivery
(3) Professional Service Team
(4) 24 hours On Line Customer Service
(5) OEM and ODM Services offered.
