Electronic IP65 Outdoor SMD LED Display PH6 , Full Color Outdoor LED Display
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
- The PFSA103D 3BSE002492R0001 motor controller offers a high degree of reliability
- Acrel Distribution transformer protection measurement and control device AM5SE-T 4-20mA analog output
- Acrel Motor differential protection AM5SE-MD measuring and controlling device is applied to high power asynchronous motor
- Acrel Bus-link protection and self-input measurement AM5SE-B and control device bus charging modbus over ethernet
- Acrel smart motor protector ARD2M K125 series protect timeout start-up overload unbalance short circuit
- Acrel smart motor protector ARD2M K125 series protect timeout start-up overload unbalance short circuit
Product Details
Brand Name: | Getron | Place of Origin: | China | Model Number: | GS8-AS-4S-PH6 |
Product Description
Certification:CCC CE EMC FCC RoHS
Outdoor SMD LED Display PH6mm with Really IP65 Waterproof Level For HD Video
Product Details:
GS8 Sun series with super high brigntness outdoor SMD LED display PH6mm. Special design aluminum module, special design aluminum cabinet, patented design, unique in the world, new generation LED display.Really outdoor SMD LED display, 10 years R&D, over 30 patents, high waterproof level, super high brightness, high contrast ratio, high grey scale, high refresh rate, super vivid color, super wide view angle, super soft display, super even surface
Quick Detail:
1. Available models: PH10mm, PH8mm, PH6mm, PH5mm…
2. high waterproof level, super high brightness, high contrast ratio, high grey scale, high refresh rate, super vivid color, super wide view angle, super soft display, super even surface
3. Light weight and easy to install
4. Perfect uniformity and no mosaic.
5. Lifespan is up to 100,000 hours.
6. Hanging structure design with gapless connection, quickly installation and dismantling
Description:
1. Light Weight
40KG for one square meter.
2. Die Casting Materials
Aluminum alloy
3. Slim Design
Cabinet size is 576mm x 576mm or any size you want on condition of integral multiple module size.
4. Easy Installation
An average worker can install more than 70 cabinets within one hour W/O tool.
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping
malls, railways, airports, harbors, etc;
Specifications:
Model No. |
GTL-G7-AS-8S-PH6 |
Pixel Pitch |
6mm |
Module Size |
192*192mm |
Module Resolution(pixels) |
32*32 |
Cabinet Size |
768mm×768mm |
Panel Resolution(pixels) |
128×128 |
Pixel Configuration(RGB) |
SMD 3 in 1 |
Pixel Density(pixels/㎡) |
27777 |
Brightness(cd/㎡) |
7000 |
Best Viewing Distance(m) |
6-100 |
Average Power Consumption(W/㎡) |
600 |
Waterproof Level |
IP65 |
Vavelength |
R 620-625 G 520-525 B 470-475 |
LED SPEC |
3129 |
Viewing Angle |
140°(H)/140°(V) |
Operating Tempreture |
–40~80°C |
Video Frame Rate(Hz) |
≥ 60HZ |
Display Refresh Rate(Hz) |
≥ 2000HZ |
Grey Level(colors) |
16.7million |
MTBF |
≥50,000 hours |
Lifespan |
≥100,000Hours |
Working Voltage |
220V±15% OR 110V±15% |
Drive Mode |
Constant 1/16 |
Graphics Card |
DVI Graphics card |
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
Control System |
LINSN |
Software |
LED studio 10.0 |
Installation |
Wall mount, hung and stand structure |
4. Methods for Quality Assurance
a. Aging
1. 100% fully test
2. Condition: 72 hours with 256 grey level
b. Vibration Testing
Condition: 3-5 mins up and down in 5mm range
5. Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SM
