High Grey Scale 16Bit Outdoor LED Video Wall Screen For Harbors / Railways

High Grey Scale 16Bit Outdoor LED Video Wall Screen For Harbors / Railways thumbnail-1
High Grey Scale 16Bit Outdoor LED Video Wall Screen For Harbors / Railways photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Getron
Place of Origin:
China
Model Number:
GS8-AB-4S-PH8
Contact Supplier Request Quote Chat Now
Shenzhen Great Tech Leds Co.,Ltd,
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Getron
Place of Origin China
Model Number GS8-AB-4S-PH8
Delivery Time:20 days
Certification:CCC CE EMC FCC RoHS

High Grey Scale 16Bit Outdoor LED Video Wall PH8mm SMD 3 In 1 LED Display


Product Details:


Special design aluminum module, special design aluminum cabinet, patented design, unique in the world, new generation LED display.

Really outdoor SMD LED display, 10 years R&D, over 30 patents, high waterproof level, super high brightness, high contrast ratio, high grey scale, high refresh rate, super vivid color, super wide view angle, super soft display, super even surface


Quick Detail:
1. Available models: PH10mm, PH8mm, PH6mm, PH5mm…
2. high waterproof level, super high brightness, high contrast ratio, high grey scale, high refresh rate, super vivid color, super wide view angle, super soft display, super even surface
3. Light weight and easy to install
4. Perfect uniformity and no mosaic.
5. Lifespan is up to 100,000 hours.
6. Hanging structure design with gapless connection, quickly installation and dismantling


Description:

1. Light Weight
   40KG for one square meter.

2. Die Casting Materials
    Aluminum alloy

3. Slim Design
    one cabinet size is 1024mm x 768mm or any size you want on condition of integral multiple module size.

4. Easy Installation
    An average worker can install more than 70 cabinets within one hour W/O tool.



Applications:


Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, etc;


Specifications:


Model No.

GS8-AB-4S-PH8

Pixel Pitch

8mm

Module Size

256*128mm

Module Resolution(pixels)

16*8

Cabinet Size

768mm×768mm

Panel Resolution(pixels)

128×96

Pixel Configuration(RGB)

SMD 3 in 1

Pixel Density(pixels/㎡)

15625

Brightness(cd/㎡)

8000

Best Viewing Distance(m)

6-100

Average Power Consumption(W/㎡)

600

Waterproof Level

IP65

Vavelength

R 620-625 G 520-525 B 470-475

LED SPEC

3129

Viewing Angle

140°(H)/140°(V)

Operating Tempreture

–40~80°C

Video Frame Rate(Hz)

≥ 60HZ

Display Refresh Rate(Hz)

≥ 2000HZ

Grey Level(colors)

16.7million

MTBF

≥50,000 hours

Lifespan

≥100,000Hours

Working Voltage

220V±15% OR 110V±15%

Drive Mode

Constant 1/16

Graphics Card

DVI Graphics card

Video Signal

RF, S-Video, RGB, RGBHV, YUV, YC, etc.

Control System

LINSN

Software

LED studio 10.0

Installation

Wall mount, hung and stand structure



4. Methods for Quality Assurance

a. Aging
1. 100% fully test
2. Condition: 72 hours with 256 grey level

b. Vibration Testing
Condition: 3-5 mins up and down in 5mm range

5. Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wir
