Help CenterKZE-B Carbon Steel High Pressure Interchange Hydraulic Hose Fittings
Related Products
-
ZJ-1141 Thread Type Stainless Steel+brass Hydraulic Quick CouplingUS$ 3 - 3MOQ: 100 Pieces -
ZJ-LA Carbon Steel Extreme High Pressure Hydraulic Quick Disconnect CouplingUS$ 3 - 3MOQ: 100 Pieces
-
ZJ-LC Thread to Connect Heavy-duty Wing Nut CouplingUS$ 3 - 3MOQ: 100 Pieces
-
ZJ-YAA ISO A Agricultural Interchange Hydraulic Quick ConnectsUS$ 3 - 3MOQ: 100 Pieces
-
ZJ-YAB ISO A Interchange Hydraulic Quick Release CouplingsUS$ 3 - 3MOQ: 100 Pieces
Features:
1. Machined from solid steel barstock for durability.
2. KZE-B Hydraulic hose fittings adopts threaded sleeve locking mechanism, mates with matchable male threads on the nipple. These two halves must be manually threaded together.
3. Hard chrome alloy ball valving. The ball can be loaded on the valve seat by the springs.
4. The valve provides a metal-to-metal seal between the ball and coined seat.
5. The interface seal is polyurethane which can bare high pressure.
6. The threaded valve retainer could stop the valve to assure the valve alignment firmly.
7. KZE-B Hydraulic hose fittings can be compatible with PARKER 3000 Series, FASTER PVVM Series.
Application:
KZE-B Hydraulic hose fittings adopts thread locking system and precision ball-type check valves design for extreme high pressure applications such as portable hydraulic jacks.
