Facture Supply Penumatic Calibration Pump

HS701 Pneumatic Pressure Comparison Pump is portable structure and designed to generate pressure from vacuum to 12bar. Built-in filter protects the pump from dirty and make maintenance convenient. External air capacitor and shut-off make the micro pressure calibration more stability. Especially the F-adjust valve design make the minimum pressure adjust get 1Pa(0.01mbar) . That is easy to calibrate less than ±25kPa of Micro pressure gauge . the design of reverse valve makes the switch of vacuum and positive pressure more smooth. Two standard pressure outputs are easy to connect gauges under test without using the wrenches. It widely calibrates pressure instruments in field and laboratory.

Technical Specification
 ◆ Generated pressure range: (-0.95-6)bar The model HS701
                                           (-0.95-12)bar The model HS701-1
 ◆ Working media: Air
 ◆ Adjust resolution: 1Pa (0.01mbar)
 ◆ Material:  Body: Stainless steel /Aluminium
                  Seals: Buna-N
 ◆ Output connection:  M20×1.5Female
 ◆ Weight:Only 2.2kg
 ◆ Dimensions:286L×198W×140H(mm)

Functions
HS701 provides pressure measurement for calibrating pressure instruments in field and laboratory. It can be extensively used in power, chemical, petrol, metallurgy, metering, military industry, etc.

Characteristics
 ◆ portable structure
 ◆ Built-in filter protects the pump from dirty and make maintenance convenient
 ◆ High stability, simple operation, convenient maintenance.
 ◆ easy to calibrate less than ±25kPa of Micro pressure gauge
