GSB Hydraulic Swing Arm Shoe Machine

GSB Hydraulic Swing Arm Shoe Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
SUMON
Model Number:
AT-20
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name SUMON
Model Number AT-20

1. There are two types of cutting modes for selection. The first type is small pressure stepless regulation. The second type is that the cutting adopts intelligent pressure feedback design function without the need of setting cutting point. The height of die cutter has no influence on the cutting and ideal cutting effect can be obtained from each cutting point.

2. Through double oil way static pressure supporting lubricating system, the vertical column makes operators' work more easy, flexible and worry-saving.

3. The main fittings are made of high quality imported assemblies, which have characteristics such as reliable quality, low noise, high efficiency and energy saving.



Maximum momentum

220kN

270kN

Seissor speed

0.15m/s

Stroke adjustment

0—70mm

0—85mm

Range between the working tables

30—100mm

30—115mm

Size of the upper rocker

360×500mm

500×500mm

Size of the pressing board

1000×500mm

Motor power

1.1kW

Overall dimension

1000×950×1350mm

1000×1000×1400mm

Total weight

650kg

780kg



we manufacture more kinds cutting machine and shoe machineGSB hydraulic swing arm shoe machineGSB hydraulic swing arm shoe machineGSB hydraulic swing arm shoe machineGSB hydraulic swing arm shoe machineGSB hydraulic swing arm shoe machine

GSB hydraulic swing arm shoe machine

GSB hydraulic swing arm shoe machine

GSB hydraulic swing arm shoe machine

Please notice more products on our web :.welcome to contact us. thanks
