SUS304 Class 100 220V Portable Clean Room 3000 , Double Door Clean Cabinet

SUS304 Class 100 220V Portable Clean Room 3000 Double Door Clean Cabinet

Quick Detail:

1.Name: 100class double door clean cabinet

2. Brand Name: YIJING

3. Material: Out cabinet Cold Steel, Inner side Stainless Steel SUS304

4. Feature: Touch-up Switching Regulator Air flowing

5. Outside dimension: 1300×680×1920 (mm)

6. Certificates: CE,ISO

Description:

The double door clean cabinet has two stainless steel doors and door stopper. The baffle is made of SUS304 stainless steel and designed with punching. The product is furnished with two baffleless ultra-thin high efficiency air filters. By taking internal circulation system, it has a much cleaner internal environment and the lifetime of the high efficiency air filter can be prolonged effectively. Meanwhile, the transparent PMMA is employed on the stainless steel doors for easy lighting and observation.

Technical Parameters

Description:

The outer housing of the double door clean cabinet is made of 1.2mm thick cold rolled steel plate and produced through plastic spraying. The product has four separated parts as the working areas. It can achieve primary, medium and high efficiency air filtration with the efficiency of 99.995% for the dust particle with the diameter of 0.3µm. The fan that the product adopts can realize stepless speed adjustment and has total six levels for speed adjusting. The soft contact computer control switch is applied on the control panel. The caster wheels of the product have two universal types, two directional types and the height adjusting mat. In addition, the removable maintenance panel on the back of the product is set for easy maintenance and air filter replacement.

In the aspects of structure and dimension, the double door clean cabinet is similar to the open type product. But the double door product adopts the clean mode of internal circulation, which can reduce the operating frequency and prolong the lifetime of the air filter. The punching design for the four baffles can link the four parts together and allow the clean air circulating in the interior of the product. Meanwhile, the double stainless steel doors are equipped to the product. The door frame is made of SUS304 stainless and has been processed with several processes including polishing. It has high glossiness.

As a China-based double door clean cabinet manufacturer, Wuxi Yijing supplies a vast range of products that includes clean room HEPA filter, cleanroom pass box, single person vertical flow clean bench, double person air shower room, and much more.

Why to choose YIJING Brand Clean Bench?

1) 15+ years experience.
2) 1000 + successful cleanroom projects completed.

3) Turnkey In-House Cleanroom Engineering and Design Capabilities.

4) Manufacturing all major components In-House.
5) Not only a manufacturer, also a specialist of cleanroom solution.

6) Multiple wall finishes to meet any standa
