YJ-VS-1 400W Single Person Use Vertical Flow Clean Bench 9907501620mm

YJ-VS-1 400W Single Person Use Vertical Flow Clean Bench 9907501620mm photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Yijing
Place of Origin:
China
Model Number:
YJ-VS-1
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Brand Name Yijing
Place of Origin China
Model Number YJ-VS-1
Delivery Time:5-10 days
Certification:CE,ISO

YJ-VS-1 400W Single Person Use Vertical Flow Clean Bench 990×750×1620mm

Quick Detail:

1.Name: YJ-VS-1 Single Person Use Clean Bench

2. Brand Name: YIJING

3. Material: Out cabinet Cold Steel, Inner side Stainless Steel SUS304

4. Feature: Touch-up Switching Regulator Air flowing

5. Outside dimension: 990×750×1620 (mm)

6. Certificates: CE,ISO

Description:

1.Usage:The product is applied with a vertical laminar flow air supply, widely used in a variety of electronics, precision instruments , pharmaceuticals , cell culture, tissue culture flowers , food, cosmetic , animal husbandry , veterinary , bio-engineering , universities and various class laboratories and other industries and research and leadership.

2. Features: Equipped with Energy-saving overhead VAV air systems, with high performance, long life and high efficiency air filters, the filtration efficiency ≥ 99.995%( sodium flame method ),the dust particle size ≥ 0.5μm, which guarantee the operating room meets U.S. Federal Standard 209E ( one hundred purification standards).

3. Smart design and user-friendly combination: Three sides of the spacious work area with high-quality 304 stainless perspective glass countertops, both effectively enhancing the comfort and spaciousness, but it is also anti-bacterial , anti-corrosion , easy to clean and functional whole work. Sealed units can be used for two -handed operation workbench holes , the hand can go into his role , while at the same raise up the entire panel , open convenient operation.

5. Safe and reliable safeguards: It is Strict accordance with international electrical safety standards designed, ensuring the product has multiple security measures , the use of soft -type UV germicidal lamp lighting control with individual control , and needs to be noted that only work before UV germicidal open sterilization, when the work does not allow people to open UV germicidal lamp , UV germicidal lamp to avoid causing burns to human skin.

Technical Parameters

Item

Data

Number of Aerobic Plate

≤0.5/m·h

Filtration Efficiency

≥0.3um (for the diameter of particle)
≥99.995% (for the dust with sodium flame method )

Average Air Flow Speed

≥0.5m/s ±20% (adjustable)

Noise

≤62dB (A)

Vibration

≤3um (in the directions of X, Y, Z)

Illumination

≥300lx

Power Supply

220V 50Hz

Illumination Lamp

20W×2

Ultraviolet Lamp

20W×2

Max. Power Consumption

400W (Rated Power)

Outside Dimension (W×D×H)

990×750×1620mm

Dimension of Operation Area

830×700×520mm

Dimension

Medium Efficiency Air Filter

437×390mm

High Efficiency Air Filter

790×600×120mm

Weight

110kg

Why to choose YIJING Brand Clean Bench?

1) 15+ years experience.
2) 1000 + successful cleanroom projects completed.

3) Turnkey In-House Cleanroom Engineering and Design Capabilities.

4) Manufacturing all major components In-House.
5) Not only a manufacturer,
