Thermostatic Shower bath Mixer 2 way wall horizontal mounted
Quick Detail:
2 way design ,will supplies water to either a fixed shower head, a handset, body jets or tub filler..... but 2 outlet work together .
Description:
Thermostatic design, means no need to adjust temperature hardly each time,never worry about scalding or drop in temperature again.
with 3 round handle and decorative plate, 1 for thermostatic control handle and 2 for outlet on/off control plate for cover the install hole .
full brass body ,
surface chrome finish ,
high flow design ,especially suitable in low water pressure but still keep normal outlet flow rate .
Specifications:
|
Weight |
5kg per piece |
|
Overall Dimensions |
(H x W) 330mmx180mm |
|
Connection |
3/4\' |
|
Material |
brass body ,zinc alloy handle |
|
Cartridge |
Ceramic Disc ,48mm dia cartridge . |
|
work pressure |
0.05Mpa-1Mpa |
|
Work temperature |
hot water supply temperature 60-70C ,cold water 5℃-29℃ |
|
Preset temperature |
Thermostatic cartridge with preset temperature stop 38°C and Separate controls for temperature outlet range 20-50 °C |
|
Temperature adjust |
Temperature control can be locked in position when setting up the required temperature , you will be able to reach the demand temperature after outlet within 5S,and the outlet fluctuate within +_2C |
|
note |
using more functions simultaneously may reduce the water flow to both outlets. |
Advantage :
1. Thermostatic control means no more fluctuations between cold and hot water
2. higher flow rates design , can work at low or high water pressure but always keep normal outlet flow rate .
3. heavy design ,5kg per piece ,strong and safe ,never corrode or rust
4. the plates are adjustable by 35mm for easier install ,suitable for any thickness of tile or grout
5. Leak Resistance: Passed the leak tests repeatedly to avoid the leak, even at high pressure up to 2Mpa
6. All components are replaceable without removing the valve ,easy maintenance
7. With non return valves ,never worry scalding or drop in temperature
8. Removable filters to trap debris
9. 1/4 turn on/off cartridge ,easy operation
10. from specialized thermostatic products manufactory ,full experience in thermostatic products more than 15 years
11. we offer full range of shower component ,can be combine to many shower set design
12. 3 year quality guarantee
