Help CenterHigh Efficiency SMD2835 4 Foot LED Tubes for Shopping Mall , 120 Degree
Related Products
-
Eco Friendly Compact T5 LED Tube 1200mm Epistar SMD2835 for SupermarketNegotiableMOQ: 1 Unit -
Super Bright SMD3528 T8 Led Tube 1200mm With 288 Pcs Leds , 6000-6500KNegotiableMOQ: 1 Piece
-
T8 2400LM 4 Foot LED Tubes SMD5630 for Production Line , Warm White / Pure White / Cool WhiteNegotiableMOQ: 1 Meter
-
1700lm Frosted Cover 4 Foot LED Tubes T8 With SMD2835 90pcs LedsNegotiableMOQ: 1 Piece
-
18 W 1800lm Transparent Cover 4 Foot LED Tubes , T8 Led Tube With 90pcs LedsNegotiableMOQ: 1 Piece
Certification:CE,ROHS
High efficiency SMD2835 4 Foot LED Tubes for shopping mall , 120 degree
Quick Detail:
1. power: 18W
2. Size:D16*1200mm
3. LM:1800
4. Color temp:2800-6500K
5. IP class:IP54
6. PF: 0.97
7. Warranty: 2 years
Description:
Size: D16*1200mm
LED quantity(pcs): 120
power- supply efficiency : 85%-87%
PF value: 0.97 above
LED angle: 120
color temp: 2800-6500K
cover type: transparant and frosted
lumen LM(per 6000k): 1800
life span: 50000H
work Temp: -30-45℃
How to install the led tube:
if you install the led tube for the new building, you can just need install this led tube only,
Specification:
| Type | 1.2m(4 feet) |
| Size | D16*1200mm |
| Led type | SMD2835 |
| Led quantity | 120 |
| Voltage | 85-277 |
| PF | 0.97 |
| Power | 18W |
| Ra | 70-80 |
| Led brand | Epistar |
Product detail:
Our Package detail:
25pcs/carton
cartion Size: 1290*25*25
volume weight:15KG
Gross weight:6.8KG
the install procedure as below:
1.Installation:
Above picture is the installation diagram of led tube light.
The first two holes in the wall with the installation, the rubber plug plugged With self tapping screws fixing clip locking to rubber plug The lamp bracket alignment clamp force press press into place The yellow green line to ground, the other two lines received a live wire and a zero line The power plug into the lamp socket2,Warning Note
Working Voltage: AC 85V～265V 50/60Hz. Do not exceed the operating voltage range. This product is prohibited material immersed in liquid. The tube is designed for moisture-proof use only. Don’t put it into water.It’s normal that the device will delay starting 2 seconds due to carrier charging after the turning on
Applications:
This led tube has the widely use:
the most important use for the commercial lighting, just as the office, supermarket, parking, it will supply us
the same power but just use the one third of the traditional fluorescent tube, so it can help us save the
power for the commercial environment,
1.suppermarket:
2.Supermarket use:
Competitive advantages:
1. Al shell:
high quality aluminum Alloy ,safe and durable, sophisticated technology thermal conductivity is strong.
2. lamp base:
high quality PC material, good flam retardant performance, anti-aging do not change color, effectively
prevent oxidation of the electronic shock.
3. lamp shade:
Delicate and high quality PC lampshade, light transmittance as high as 98%, refraction light even high
degree of safety service life is long.
4. lamp bead:
led super bright light bead, avirulent environmental protection, high conversion rate, lamp bead uniform
distribution the heat better.
Certification:
FAQ:
Q: Nearly all LED tube T5 are the same exterior,how to tell quality?
A: Price and exterior.
Though LED lighting products are with same or similar exterior,due to raw material cost difference is big,poor quality are all poor housing exterior with short FINs and light weight.So prices are also low.
Besides,the driver exterior is also low-end with poor IC,MOS and capacitances.
Q:Does LED tube T5 really have 50,000 hours lifespan?
A:50,000 or longer lifespan is only theroy from lab test.But due to working enviroments are different from in lab,actual lifespan is only <=30,000hours.
Especially for LED high bays and LED floods,the power is very huge,and lots of heat cause LEDs junction temperature very high.And light decay will be higher than low power LED products.
Our LED tubes are in the market over 7 years,and according to feedbacks from our clients,nearly no faluire in 4-5 years.
Q:For same power,why different suppliers with different brightness?
A:Different chips,or same chip but different brightness version.The brightness will be different.But for same c
