Hanging Full Color Outdoor Advertising LED Display P10 10000 Pixels / m²
Quick Detail:
1.3 years warranty
2 Good consistencies
3 Excellent visual effect
4 Good quality match good price
5.Good price and good service
Description:
1. Cabinet is stronger without distortion, anti-rust.
2. Synchronously adjust the brightness and color to make the true and exquisite image.
3. High contrast, high refresh rate make the image without any delay, trailing smear.
4. Special wooden box package production protect the whole screen system.
5. PCB patent technology, the most stable signal transmission technology in the world.
Applications:
Shopping malls
Postal offices
School
Monitoring
Restaurants
Entertainment
P10 hot sales outdoor full color led display
Specifications:
|
Part Number |
TeehoLED-P10 |
|
Resolution |
16(H)×16(V) |
|
Pixel Pitch |
10mm |
|
LED Configuration |
1R1G1B -DIP |
|
Pixel Density |
10,000 pixels/ m² |
|
Module Size |
160×160mm |
|
Cabinet Size |
960×960mm, 960×800mm, 800×800mm, etc. |
|
Driving IC |
MBI5024 |
|
Driving Method |
1/4 Scan, Constant Current |
|
Weight |
58KG/sq.m. |
|
Mechanical Ratings |
|
|
Hanging Weight Support |
2T |
|
Surface Flatness |
Gap<0.5mm |
|
Optical Ratings |
|
|
Brightness |
7000CD |
|
View Angle |
120°/60° |
|
Gray Scale |
8bits input, correction with 14bits |
|
Display COLOR |
16.7M |
|
Brightness Adjustment |
0～100% 10 level |
|
Power Supply |
|
|
Operation Power |
90～260V 50～60Hz |
|
Max. Power Consumption |
1000W/ m² |
|
Average Power Consumption |
320W/ m² |
|
Control System |
|
|
Control Mode |
Synchronous display with control PC by DVI |
|
Frame Update Frequency |
60～85Hz |
|
Screen Refresh Frequency |
300～1000Hz |
|
Gamma Correction |
-5.0～+5.0 |
|
Support Input |
Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
|
Control Distance |
Ethernet cable<120m or Fiber Optic<10Km |
|
Support VGA Mode |
1024×768, 1280×1024, 1600×1200, 1920×1280 |
|
Brightness Correction |
Pixel, Module, Cabinet |
|
Environmental |
|
|
Operating Temperature |
-20°～+60° |
|
Operating Humidity |
10～95% RH |
