Full Color SMD Indoor Rental LED Display Screen Hire P5 1R1G1B , 40000 pixels / ㎡
Quick Detail:
Light weight & super slim Quickly and easily installed High refresh rate Beautiful surface designFull Color 1R1G1B 3-IN-1 SMD Indoor Rental Led Screen For Television Relay,8S Die Casting Aluminum P5 indoor rental display, 8S P5 Indoor Rental LED Display With Die Casting Aluminum Cabinet
Description:
1. Ultra thin and slim design
2. HD video with vivid pictures
3. Hanging beam structural design makes it easy and fast for installation
4. locks on both sides of cabinet contribute to uniformity and flatness of two neighboring cabinets.
5. Neat and Hidden Wiring allow the led display more tidy and beautiful.
Applications:
Stage Background
Airport & Station
Television Relay
Information Display
Stadium
Event Show
Specifications:
|
Part Number |
Teeho-P5－8S |
|
Resolution |
32(H)×32(V) |
|
Pixel Pitch |
5mm |
|
LED Configuration |
1R1G1B 3-IN-1 SMD |
|
Pixel Density |
40,000 pixels/ ㎡ |
|
Module Size |
160mm*160mm |
|
Cabinet size |
640x 640x7mm |
|
Driving IC |
MBI5024 |
|
Driving Method |
1/8 Scan, Constant Current |
|
Cabinet Weight |
8kg/sq.m. |
|
Mechanical Ratings |
|
|
Hanging Weight Support |
2T |
|
Surface Flatness |
Gap<0.5mm |
|
Optical Ratings |
|
|
Brightness |
1,800cd/ m2 |
|
View Angle |
150°/150° |
|
Gray Scale |
8bits input, correction with 14bits |
|
Display COLOR |
16.7M |
|
Brightness Adjustment |
0～100% |
|
Power Supply |
|
|
Operation Power |
90～260V 50～60Hz |
|
Max. Power Consumption |
850W/ ㎡ |
|
Average Power Consumption |
280W/ ㎡ |
|
Control System |
|
|
Control Mode |
Synchronous display with control PC by DVI |
|
Frame Update Frequency |
60～85Hz |
|
Screen Refresh Frequency |
300～1000Hz |
|
Gamma Correction |
-5.0～+5.0 |
|
Support Input |
Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
|
Control Distance |
Ethernet cable<120m or Fiber Optic<10Km |
|
Brightness Correction |
Pixel, Module, Cabinet |
|
Environmental |
|
|
Operating Temperature |
-30°～+60° |
|
Operating Humidity |
10～95% |
