Automatic PLC Panasonic Corrugated Curving Machine CV28-200-1000

CV28-200-1000 Hydraulic Curving Machine, Driven By Servo Motor, Curving By Hydraulic Pressing

Main features

a,the structure is simple and the appearance of the machine is beautiful because we adopt the shape-steel structure and process as a whole after welding. it has the ability of strong loading and stable operation when running the machine.

b．All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.

c,we adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming .

       d: it is very easy to install the equipment and suitable for producing in the factory.

e: the machine has features of low noise and high efficiency.

Main Specifications


Competitive Advantage:

Products Photos

YX28-200-1000

1: Coil width: 1220mm   effective width: 1000mm

2: working speed: 12-15m/min (not contain cutting)

3: roll station: about18stations

4: material of roller: grade 45 steel, polished and coated with chrome

5:material of main shaft:45﹟forge steel   diameter roller: Ф70mm

6: main power: 7.5KW

7: forming thickness: 0.2mm—0.8mm zinc and color steel, G250Mpa

8: Transmission: by single Chains 1.0 inch

9: feeding and guide: surface polished and coated with chrome

10: machine drive parts adopt protect cover

11: machine adopt new station with chrome

12: size of main machine: Appro7500x1400x1200(mm)   L x W x H need 1x40GP container

13: weight: about 5600Kgs

14: color of machine: blue (also can choose by customer request)

15: machine should be with four legs (made from metal) in 350mm

16:  Cutting:

(1)  Hydraulic Cutting after forming: Cut the sheet after roll forming to required length

(2)  Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.

(3)  Material of blade: CR12with heat treatment

(4)  Length measuring: Automatic length measuring

(5)  Tolerance of length: 3m 1.5mm

.
Guarantee:
1:Guaranteed against malfunctions due to manufacturing defects for 1 year after date of purchase. Repairs will be made free of charge.
2:Reparis will not be performed free of change even during the guarantee period in the follow circumstances
-  damage occurs due to a natural disaster
-  malfunction occurs due to user error
-  malfunction occurs due to modifications
-  malfunction occurs due to further movement or shipment after installation
3:Air ticket, transportation cost, hotel, meals and 60$ per day shall be for purchaser’s account if manufacturer’s engineer has to be send to purchaser’s factory to maintain the machine during the guarantee period.
