Help CenterSteel Structure Sheet Floor Decking Roll Forming Machine With 11KW Mortor Driven
Related Products
-
Customized Silver Durable Metal Deck Roll Forming Machine With PLC Control SystemUS$ 35000$ - 45000$MOQ: 1 Piece -
Corrugated Sheet Metal Deck Roll Forming Machine 22KW With Hydraulic Cutting SystemUS$ 35000$ - 45000$MOQ: 1 Set
-
Galvanized Steel Sheet Roofing / Floor Deck Roll Forming Machine 15m/minUS$ 35000$ - 45000$MOQ: 1 Set
-
Galvanized Steel Sheet Metal Deck Roll Forming Machine Sheet Metal Roll FormerUS$ 35000$ - 45000$MOQ: 1 Set
-
22KW Deck Roll Forming Machine Cold Roll Forming Equipment 0.8-1.6mm ThicknessUS$ 35000$ - 45000$MOQ: 1 Piece
Certification:CE
0.7 - 1.6mm Thickness & 980 Cover Width Metal Deck Roll Forming Machine With 22KW Motor,Hydraulic Cutting System
Composition of machine
|
Roll forming main machine |
1 unit |
|
Roll forming main machine |
1 unit |
|
5T manual de-coiler |
1 unit |
|
Control panel |
1 unit |
|
Hydraulic station |
1 unit |
|
Manual out table |
2 unit |
|
Spare tools |
1 unit |
Main Specifications
|
Coil Material |
Thickness |
0.8-1.2mm |
|
Coil width |
Depend on customer’s requires |
|
|
Yield Strength |
360N/mm2 |
|
|
Material |
Galvanized steel sheet |
|
|
Decoiler / Uncoiler |
Coil Width |
Max. 1500mm |
|
I.D |
510-610mm |
|
|
O.D |
Max. 1300mm |
|
|
Capability |
Max. 5 Tons |
|
|
Decoiler type |
Manual / Hydraulic/Automatic |
|
|
Feeding & Leveling |
Pinch feeding |
1 Units ( 2 Rollers ) |
|
Cutting device |
Cutting motion |
Hydraulic Cutting, post-Cutting ( cutting sheet after forming ) |
|
Cutting blades |
Cr12Mov with heat treatment HRC58-62 |
|
|
Length Measuring |
Automatic length measuring by encoder & PLC. |
|
|
Cutting Tolerance |
1.5mm(per 3m) |
|
|
Roll Forming Machine |
Forming Stations |
24Stations |
|
Press Roller |
One station press roller to make pressing for profile |
|
|
Rectifying |
1 unit |
|
|
Roller material |
GCr15 steel, heat treatment |
|
|
Diameter of shaft |
80mm |
|
|
Shaft material |
High grade 45# steel |
|
|
Drive type |
Chains |
|
|
Forming speed |
15m/min |
|
|
Main power |
22KW (11kw *2) |
|
|
Servo motor |
1 Units |
|
|
Driven System |
Driven by Motor |
Transmission by chains |
|
Electrical control |
PLC |
PANASONIC Brand or Custom-made |
|
Inverter |
YASKAWA Brand or Custom-made |
|
|
Touch screen |
MCGS Brand or Custom-made |
|
|
Operation type |
Touch screen & Button |
|
|
Hydraulic Station |
Hydraulic station |
Famous Chinese brand |
|
Hydraulic power |
7.5KW |
|
|
Runout Table |
Table type |
Simple non-power type |
|
Function |
To support the finished panels |
|
|
TOTAL WEIGHT |
APRRO 8 TONS |
Products Photos
Competitive Advantage:
Economical Simple Standard speed High Quality Reliable Durable Reasonable Price Good after Service 1 Year Warranty More Than 10Years Experience.
Guarantee:
