Extruded Seamless Aluminium Tube 6082-T6 Cu 1.2 - 2.0 , Oxidation Resistance
1) Alloy:
1015,1050-H1,1060-H1/1070-H1,2011,2014-T6,2017-T4,2024(2A12)-T4,3003-H1,5005,5052-H34-H38,5154,5056-H32-T0/5083-H22,6106,6201,6011,6351,6060,6063-T5-T6-T83,6061-T4-T6,6005,6082-T6,6463,6262,7001,7003,7075-T651-T6-T0,7050,7075,7005-T0 etc.
2) Specification range :
Seamless round pipe :dia:10-185mm,wall thickness: 1.5-30mm
Rectangular tube: 10*10-100*100MM
Some other details size could ordered according clients request .
3) Surface: Degreased, anodized, mill finish etc.
4) Delivery time: 7-15 days after confirming order.
5) Minimum order quantity: 1 tons per size.(or according the actual condition)
6) The term of payment: T/T, irrevocable L/C at sight.etc
7) Packing: Export standard packing : PP bag ,wooden box or other packing according clients request .
8) Feature:anticorrosion etc.
9) 1000ton/month
7001/7075 etc aluminum pipe production technology
1.Aluminum bar through the peeling after punch 1200 t extruder extrusion forming Ø and x 2.0
2.Large diameter through the cold machine after cold drawn, with fire degradation process to the necessary
3.specifications, is commonly Ø 8.5 x 0.72 ~ Ø 7.9 x 0.72 MM
4.Aluminum tube forming later, straightening machine straightening, cutting machine cut to size
5.Chamfering process, is the place where the cut hair cut into smooth
6.Surface oxidation color for the core assembly, cut loose fire
7.Assembly product
7075 aluminum is a cold treatment forging alloy, high strength, and far better than mild steel.
7075 aluminum tube is one of the most powerful alloy in business. Common corrosion resistance,good mechanical capacity and anodic reaction. Fine grain can make the deep drilling performance even better, tool abrasion resistance increase, and thread rolling is more different.
7075 aluminum chemical component
| Alloy, chemical composition, mechanical properties | |||||||||||||
| chemical composition(The mass fraction)% | |||||||||||||
| grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Zr | remark | AL | |
| 7075 | 0.40 | 0.50 | 1.2~2.0 | 0.30 | 2.1~2.9 | 0.18~0.28 | --- | 5.1~6.1 | 0.20 | -- | single:0.05 | total:0.15 | the rest |
| Mechanical properties | |||||||||||||
| state | thickness | Tensile strength Rm/Mpa | Extension strength Rp0.2/Mpa | Elongation/% | |||||||||
| A | A50mm | ||||||||||||
| ≮ | |||||||||||||
| T6 | ≤25 | 530 | 460 | 6 | 4 | ||||||||
|
T6510 T6511 |
>25~60 | 540 | 470 | 6 | - | ||||||||
|
T73 T73510 T73511 |
≤25 | 485 | 420 | 7 | 5 | ||||||||
| T76 | ≤6 | 510 | 440 | -- | 5 | ||||||||
|
T76510 T76511 |
>6~50 | 515 | 450 |
