Help CenterGCT Engine 2.5 Ton Gasoline Forklift Truck Red For Construction CPQD25
Related Products
-
1.8 Ton Off Road Gasoline Forklift Truck With Nissan Engine For Material Handling CPQD15NegotiableMOQ: 1 Square Meter -
Solid Tyre 3 T Gasoline Forklift Truck With Nissan Engine For Storage Yard CPQD30HNegotiableMOQ: 1 Set
-
Hydraulic / Auto 2 T Gasoline Forklift Truck , Industrial Fork Lift Truck SafetyNegotiableMOQ: 1 Ton
-
2500KG Gasoline Powered Forklift Truck Red , Counterbalance Fork LiftNegotiableMOQ: 1 Metric Ton
-
Airport / Sea Port Gasoline Forklift Truck 2500kg With 3000mm Lifting HeightNegotiableMOQ: 1 Square Meter
Certification:CE / SGS / ISO9001 / ISO14001 / SGS
Quick Detail:
1, Material Handling, loading & unloading cargo, moving cargo in pallets,
2. Gasoline forklift truck, Gasoline power forklift
3. 2500kg rated capacity, 3000mm lifting height, 500mm load center
4. Sea Port, Airport, Warehouse, Construction, factory
5, NISSAN ENGINE , GCT ENGINE
Description:
HS Code: 8427209000
Trademark: JAC
Export Market: Global Market
Certificate: CE / SGS / ISO9001 / ISO14001 / SGS
Production Capacity: 20000 unit/year.
Forklift Type: Gasoline Forklift
Model Number: CPQD25J Load Capacity: 2500KG
Engine: NISSAN ENGINE / GCT ENGINE / CHINESE ENGINE
Transmission: Hydraulic/Auto (with TCM Technology)
Standard Mast: Standard 2-Stage Tower Mast (3.0m)
Container Mast(Optional): Duplex / Triplex full free Mast (3.0-6.0m)
Tyre: Pneumatic Tyre (Standard) Solid Tyre (Optional)
Side shift (optional): Integral side shift / Cascade side shift
Applications:
Material Handling, loading & unloading cargo, moving cargo in pallets in warehouse, factory building, storage yard, airport, sea port, super market.
Specifications:
| Model | CPQD20 | CPQD25 | |
| Power type | LPG | ||
| Rated capacity | Kg | 2000 | 2500 |
| Load center | mm | 500 | 500 |
| Lift height | mm | 3000 | 3000 |
| Length to face of fork | mm | 2536 | 2596 |
| Overall width | mm | 1190 | 1190 |
| Mast lowed height | mm | 1995 | 1995 |
| Mast extended height | mm | 4015 | 4015 |
| Overhead guard height | mm | 2105 | 2105 |
| Turning radius (outside) | mm | 2245 | 2300 |
| Wheelbase | mm | 1600 | 1600 |
| Self weight | Kg | 3400 | 3800 |
| Engine Manufacturer | NISSAN | ||
| Fuel Type | Gasoline | ||
| Engine Type | k25 | ||
| Engine Power (KW/rpm) | 37.4 / 2300 | ||
| Max.Torque (Nm/rpm) | 176.5 / 1600 | ||
| Number of Cylinder | 4 | ||
| Displacement (L) | 2.488 | ||
| Bore x Stroke | 89 X 100 |
Competitive Advantage:
1. Stream-line design: Exclusive streamline design, fashionable and spirituality.
2. Powerful Engine: Equip with high performance and quality engine: ISUZU, VM, YANMAR.
3. High performance shell hydraulic oil: Protect key spare parts and prolong working life.
4. Safety belt seat: Safe, comfortable and equip with warning system without fasten seat belt.
5. High exhaust fans: Provide better working environment for operator.
6. Integrated overhead guard: Well protect the operator
7. Hydraulic shift and key-switch type flame-out device: Operation and flame-out more easier.
8. Up market meter and car parking type brake: Totally enclosed car type meter desk, car parking type brake save effort for operation.
9. Side shift: Standard equip with side shift, operation more easier and improve work efficiency.
