Waterproof P7mm LED Advertising Screens , 32*32 Outdoor LED Video Wall For Airport

FOB Price

USD $2100 - $2300 / / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	lysonled		Place of Origin	China
Model Number	P7 DIP Outdoor LED Display Screen

Product Description

Delivery Time:10~15 working days
Certification:CE ROHS ISO

Waterproof P7mm LED Advertising Screens , 32*32 Outdoor LED Video Wall For Airport

Quick Detail:

1) Stable quality:Opto + Silan chipset;

2) High brightness:>10000 nits;

3) Scan driver:1/4 current;

4) Module size(L*W):224*112mm;

Description:

P7 DIP Outdoor Full Color LED Display Screen

7mm pixel pitch,1R1G1B,20408 dots/sqm,P7 DIP Outdoor Full Color LED Display Screen creates high brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P7 DIP Outdoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

Applications Occasions:

Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

Specifications:

P6mm P7mm P8mm P10mm DIP Outdoor LED Display Screen:

Module	Pitch/mm	P6	P7	P8	P10
Module size/mm	192*192	224*112	256*128	320*160
Density of pixel/(dots/m2)	27778	20408	15625	10000
Pixel composition	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Led encapsulation	DIP	DIP	DIP	DIP
Resolution of module	32*32	32*16	32*16	32*16
Main	Optimum viewing distance	≥5	≥6	≥7	≥8
View angle / °	V60/H120	V60/H120	V60/H120	V60/H120
Average power consumption/W/M2	650	600	550	500
Max power consumption/W/M2	1300	1200	1100	1000
Size of cabinet/mm	768*768	896*672	768*768	1280*960
Resolution of cabinet	128*128	128*96	96*96	128*96
Frame frequency / Hz/S	≥60	≥60	≥60	≥60
Refresh rate Hz/S	≥600	≥600	≥600	≥600
Luminance of white balance	≥11000nits	≥10000nits	≥8000nits	≥8000nits
Weight of cabinet/kg/sqm	55
Driving method	1/4 scan constant current
Operation of Environmental Temperature/°C	below 30 to above 65
IP rating	Front,IP65;Rear,IP43
Working vlotage	110-220 VAC/ 10%
Grey scale/color	displaying colors≥16.7M(synchronized)
Brightness adjustment	256 levels of each color(manually),100 levels of each color(automatically)
