Qlogic QLE2562 Fibre Channel Card 8Gb PCIe Dual Channel HBA

Qlogic QLE2562 Fibre Channel Card 8Gb PCIe Dual Channel HBA

Features

QLogic QLE2562 is a PCI Express, dual-port Fibre Channel (FC) host bus adapter (HBA). QLE2562 is part of the QLE2500 HBA product family that offers next generation 8Gb FC technology to meet the business requirements of the enterprise data center. This HBA features include 3200 MBps throughput (full duplex) per port 200,000 initiator (initiator) and target (target side) IOPS and StarPower ™ technology based on dynamic and adaptive power management. Its benefits include virtualization, power, RAS, and for the optimization of safety.

Technical Specifications

Architecture
Dual-port 8Gb Fibre Channel
200,000 per port initiator (initiator) and target (target side) IOPS
Provides full duplex / port up to 3200 MBps throughput
256 queues for enhanced virtualization performance
Authentication (FC-SP), fiber-level SAN isolation level (NPIV) and end data integrity (T10)
By StartPowerTM Link Training to achieve dynamic power management
Unified HBA drivers and firmware architecture
Fibre Channel specifications
8/4/2 Gb auto-negotiation
Service Level  2 and 3
Topology  FC-AL, FCAL2, point to point, switch fabric
Protocol  FCP-3-SCSI, FC-Tape (FCP-2)
HBA Distance Support  8Gb rate multimode fiber (with a variety of cable types) - OM1-21m, OM2 = 50m, OM3-150m

Applicable Host   IBM, HP, DELL, SUN, intel, wave, Lenovo, Dawning, Proudly ..... other brands servers and workstations.

Supported operating systems

Windos XP / Vista

Windows Server 2000/2003/2008/2008 R2 / 2012

linux Red Hat / Novell SLES
Solaris X86 / SPARC
Netware6.5
VMware ESX / ESXi
Apple Mac OS X
Citrix XenServer
