Product Details
Brand Name: | HAIJUN | Place of Origin: | China | Model Number: | R6M 1strand |
Product Description
Continuous Caster Machine
Quick Detail:
radius: R6M
Strand number :1 strand
with ISO certification
advanced design
safe operation
We can produce high quality continuous casting machines from 1 to 8 strands with the lowest equipment manufacturing cost.We can design, manufacture the up-to-date billet continuous casting machine in accordance with the user\'s steelmaking capacity, billet size, steel grades and the user\'s field conditions.
Description:
1. Basic standby technical parameters:
Steel billet casting machine radius |
6m |
Strand quantity |
1 strand |
Ladle support type |
Ladle car or ladle turret |
Tundish carriage |
Semi-portal, cross sliding function |
Casting method |
Metering nozzle, open casting |
Secondary cooling |
Water cooling , 1 adjusting circuit |
Withdrawal straightening machine |
Totally 5 roller, progressive straightening |
Roll table |
Chain group centralized drive |
Dummy bar |
Rigid, with self-adapting dummy bar head |
Billet cutting |
Flame cutting machine |
Billet conveying |
Group centralized live roller table |
Cooling bank type |
Simple cooling bed |
2. Technical process description and capacity of steel billet CCM
Induction furnace:
Nominal capacity |
10T |
Tap-to-tap cycle |
60min |
Furnace quantity |
2set |
Production capacity
Working days |
330 days/year |
Average number of daily furnace |
24/day |
Production capacity |
100,000t/year |
3. Casting speed, productivity and strand quantity
R6m radius casting machine can cast steel groups of different specifications, the maximum casting speed is as follows:
Casting sectional area(mm) |
100×100 |
125×125 |
150×150 |
Casting speed(m/min) |
3.0 |
2.7 |
2.5 |
NO. |
Billet size |
Casting speed |
hourly output (tons) |
Daily output 24hour (tons) |
Annual output(330days) (tons) |
1 |
100×100 |
3.0m/min |
12.01 |
288. |
95123 |
2 |
125×125 |
2.7m/min |
16.89 |
405 |
133,767 |
3 |
150×150 |
2.5m/min |
21.72 |
508 |
