Flexible High Power LED PCB Board for LED Aquarium Light 8W , 16W , 36W
- 0 Meter / Meters per Month
- T/T L/C D/P D/A
- 7 days
- China factory lighting manufacturers 6063 Aluminium LED wall wash lighting housing
- Industrial Lighting IP65 LED Tunnel Lamp Cover
- Industrial Lighting IP65 LED Tunnel Lamp Housing
- Industrial Lighting IP65 LED Tunnel Lamp Shade
- Industrial Lighting IP65 LED Tunnel Light Lamp Cover
- Industrial Lighting IP65 LED Tunnel Light Lamp Housing
Product Description
Flexible High Power LED PCB Board for LED Aquarium Light 8W , 16W , 36W
Specifications
Base Material: Aluminum
Layer: 1 layer
Board Thickness: 0.4mm~3mm
Board Dimension: 165x24mm,365x24mm,570x24mm(it can be customized)
Copper layer: 1oz
Solder Mask: White
Silkscreen: Black
Surface finish: LF HAL
Outline Profile: CNC routing/V-Cut/Punching
All of the parameters can be customized!
Applications
It can be use 2835,5630,3014,2323,3535,1W high power LEDs
Special for 8W,16W,18W,22W,24W,30W,36W LED Aquarium Light
Lead Time
Samples: 3-4 days
Mass Production: 7-15 days(depend on the quantity)
Payment Terms
T/T,Western Union
Packing and Shipment
Vacuum package in carton
Factory Capability
Item |
Manufacturing Capability |
Surface Treatment |
OSP |
PCB Layer Type |
Single side,Double side |
Max. Working Panel Size |
1500mm*600mm |
Min. Working Panel Size |
4mm*4mm |
AL Substrate Thickness |
0.3mm-4mm |
Min. Conductor width |
0.15mm |
Min. Conductor spacing |
0.15mm |
Min. Drilling hole size |
0.2mm |
Plate Thickness Tolerance |
±0.1mm |
Finished Panel Tolerance |
±0.1mm |
V-CUT Alignment |
±0.1mm |
Hole Dia Tolerance |
±0.05mm |
Hole Position Tolerance |
±0.076mm |
Finished Copper Thickness |
35um-105um(1oz-6oz) |
Etching Under Cut |
>/=2.0 |
PTH&Panel Plating Uniformity |
>90% |
Eing/Flash Gold Thickness |
1-5u’’ |
Solder Mask Thickness |
15um-35um |
Min. Solder Mask Bridge |
0.076mm(3mil) |
Silk Screen |
White/Black(depend on your requirements) |
Thermal Conductivity |
1.0~20W/MK |
Withstand Voltage |
AC 2000V,DC 1500~4000V |
JHD PCB would like to be your reliable partner in near future!
