Derrick Travelling Block Drilling Rig Parts for ROTARY TABLES 2700-9000KN
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
KOMAL
Place of Origin:
China
Model Number:
ZP175
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Gas Drilling Travelling Block Drilling Rig Parts for Swivel Max. Speed 300r/minNegotiableMOQ: 1 Piece -
High Performance Drilling Rig Parts Travelling Block Draw Works 210-1470KWNegotiableMOQ: 1
-
Drilling Rig Parts Travelling Block Hoist System for Crown Block 1350-6750KNNegotiableMOQ: 1 Piece
-
Hoisting System Drilling Rig Parts Travelling Block of Max.Load (KN) 300-2700NegotiableMOQ: 1 Set
-
XJ350 XJ400 Workover Rig / Truck Mounted Rig on Derrick , Max. 1000KNNegotiableMOQ: 1
Brand Name
KOMAL
Place of Origin
China
Model Number
ZP175
Delivery Time:15days
Certification:API
Certification:API
Traveling block,Drilling rig parts for ROTARY TABLES 2700-9000KN
Description:
Applications:
It’s the parts of drill rig,used on derrick,the hoist system for oil and gas drilling,oil field
Specifications :
TECHNICAL PARAMETERS
| Model | ZP175 | ZP205 | ZP275 | ZP375 | ZP375Z | ZP495 |
| Table opening mm(in) | 444.5 (171/2) | 520.7(201/2) | 698.5(271/2) | 952.5(371/2) | 952.5(371/2) | 1257.3(491/2) |
| Static load rating (kN) | 2700 | 3150 | 4500 | 5850 | 7250 | 9000 |
| Max. working torque N.m | 13729 | 22555 | 27459 | 32362 | 45000 | 64400 |
| Distance from table axis to center innerrowof sprocket teeth mm(in) | 1118(44) | 1353(53 1/4) | 1353(53 1/4) | 1353(53 1/4) | 1353(53 1/4) | 1651(65) |
| Gear ratio | 3.75 | 3.22 | 3.67 | 3.56 | 3.62 | 4.0883 |
| Max. speed r/min | 300 | 300 | 300 | 300 | 300 | 300 |
| The center height of input shaft mm | 260.4 | 318 | 330 | 330 | 330 | 368 |
| Overall dimensions (L x W x H) mm | 1972x1372 x566 | 2266x1475 x704 | 2380x1475 x690 | 2468x1920 x718 | 2468x1810 x718 | 3015x2254 x819 |
| Net weight (include master bushing and exclude sprocket) kg | 4172 | 5662 | 6122 | 7970 | 9540 | 11260 |
Competitive advantages:
Competitive price with top quality,professional export service,provide all products as customer’s requirement,respond within shortest time
