Quick Detail:
Item: PU Sandwich Panel
Model: 970
Available thickness: 30-120mm
Base Material: Prepainted galvanized steel
Zinc coating: 60-120g/m2
Color: White, Blue, Green, Red, Beige, etc(according to RAL Color Chart)
Description&Application:
Polyurethane Sandwich Panel also called PU Sandwich Panel,the up & down surface of this panel is Galvanized & Pre-painted steel sheets,
core material is 5 components Polyurethane glue, it is formed by heating, foaming & laminating. Polyurethane is the best material for temperature
keeping and sound insulation. It is widely used as the wall or roof for cold storage, industrial workshop, public building etc.
Main features:
Easy to install, shorten the construction period; Compact connection, excellent waterproof performance; High loading capacity and strength.Specifications:
|
ITEM |
Contents |
POLYURETHANE(PU) |
|
STEEL SHEET ON BOTH SIDE |
THICKNESS |
0.4-0.5MM PREPAINTED GALVANIZED STEEL |
|
CORE MATERIAL |
MATERIAL |
POLYURETHANE FOAM |
|
DENSITY |
35-40KG/M3 |
|
|
FIRE PROOF |
B2 CLASS |
|
|
THERMAL CONDUCTIVITY |
≤0.027Kcal/mh’c |
|
|
MOISTURE ABSORPTION RATE |
UNDER 3.0% |
|
|
SIZE |
THICKNESS |
30MM-120MM |
|
EFFECTIVE USING WIDTH |
970MM |
|
|
LENGTH |
UNDER 12M |
Competitive Advantage:
Good fireproof performance; Environmental protection. SpecificationsEPS Sandwich Panel, PU Sandwich Panel, Polystyrene Sandwich Panel,Polyurethane Sandwich Panel, Rock Wool Sandwich Panel,Sandwich
Product Description
PU Sandwich Panel is composed by two layers of weatherproof colored steel and injected the expanded polystyrene in middle.
1) Item:PU Sandwich Panel
2) Model:970(for Roof)
3) Crest height:40mm
4) Thickness for PU: 50mm,75mm,100mm
5) Thickness for steel sheet: 0.3mm-0.5mm
6) Length: any length we can do according to your request
7) Length tolerance: 5mm
8) PU density: 35-40kg/m3
9) Character: Light in weight, heat insulation, competitive in price
10) Application: Roofs for Warehouse, gymnasium,exhibition halls, storage
System Features:
·thermal insulation
·sound insulation
·corrosion resistant
·earthquake resistance
·dirt resistance
·wind resistance
·waterproof & moisture resistance
·green
