Custom Ajustable Convenient Tank Rotator , Self-aligned Welding Turning Rolls
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Yijie
Place of Origin:
China
Model Number:
SAR
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
1200 Ton Conventional Welding Tank Rotator For Construction Of Wind TowerNegotiableMOQ: 1 Piece -
Fit-up Horizontal Tank Turning Rolls , Self-aligning Pipe Welding RotatorsNegotiableMOQ: 1 Piece
-
Horizontal Adjustment Tank Turning Rotator For Construction Of Steel VesselNegotiableMOQ: 1 Piece
-
Horizontal Self-aligned Vessel Tank Rotator Welding Machine To Weld In BlueNegotiableMOQ: 1 Set
-
Industrial Conventional 100 Ton Tank Welding Turning Roll Of Hydraulic LiftingNegotiableMOQ: 1 Piece
Brand Name
Yijie
Place of Origin
China
Model Number
SAR
Delivery Time:15--25days
Certification:CE
Notes:
a) Custom built fit up rolls available. Required information: i) Tank weight, ii) Vessel diameter range (min- max)
b) Vertical adjustment of work piece: Both wheels of the same rotator has hydraulic lifting device which allows the wheels to move synchronized (right/left or left/right). While the wheel moves horizontally the work piece is lifted/lowered vertically
c) Horizontal adjustment of work piece: Two rotators have a hydraulic device which allows each wheel to move independently (right/left or left/right) for horizontal adjustment
d) Fit up detailed sequence: Available under customer request
e) Inside and outside circumferential seam welding: By means of a Welding Manipulator WM Series with SAW head
Certification:CE
Custom Ajustable Convenient Tank Rotator , Self-aligned Welding Turning Rolls
it Up Rolls, FUR SERIES: Designed for align and assembling shell to shell or section to section, round and conical. Ideal for construction of wind towers, steel vessels and tank
Standard package includes: a) One power rotator Model FUR WR with control box and 12.00 meters length remote control for adjusting of rotating speed, stop, forward, and reverse. Digital speed indicator set for mm/min is included, b) Three idler rotator Model FUR IR, c) Operation manual, d) One year guaranty.
Optional: a) Foot control pedal for control forward, stop and reverse rotation; b) Extra idler rotators Model FUR IR-IB may be required depending of work piece length; c) Rail tracks
Standard package includes: a) One power rotator Model FUR WR with control box and 12.00 meters length remote control for adjusting of rotating speed, stop, forward, and reverse. Digital speed indicator set for mm/min is included, b) Three idler rotator Model FUR IR, c) Operation manual, d) One year guaranty.
Optional: a) Foot control pedal for control forward, stop and reverse rotation; b) Extra idler rotators Model FUR IR-IB may be required depending of work piece length; c) Rail tracks
Notes:
a) Custom built fit up rolls available. Required information: i) Tank weight, ii) Vessel diameter range (min- max)
b) Vertical adjustment of work piece: Both wheels of the same rotator has hydraulic lifting device which allows the wheels to move synchronized (right/left or left/right). While the wheel moves horizontally the work piece is lifted/lowered vertically
c) Horizontal adjustment of work piece: Two rotators have a hydraulic device which allows each wheel to move independently (right/left or left/right) for horizontal adjustment
d) Fit up detailed sequence: Available under customer request
e) Inside and outside circumferential seam welding: By means of a Welding Manipulator WM Series with SAW head
Product Application:
Used to weld, polish and assemble the cylinder-shells, and to line the shells with rubber. Wide wheels rollers, to enhance the friction force between the wheels and tank, conventional + self aligned roller, to suit large diameter range of the tank, motorized lead screw rollers, to reduce labor force when changing the wheel distance of heavy capacity of rollers, Pu wheels, for stainless steel tank turning, full steel wheels, for heavy weight tank turning.
Product Advantage:
Fit-up type, convenient
high quality
Reasonable price
good service
Competitive Advantage:
We can make all kinds of rollers according different customers different requests. Max. Loading capacity can reach:2000tons, self-aligned or adjustable roller beds/turning rolls.
