Home > Products > Aluminium Composite Signs > Light Weight Aluminium Composite Sign Board Panel For Outdoor Advertise ECCA Standards
Light Weight Aluminium Composite Sign Board Panel For Outdoor Advertise ECCA Standards
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | MAXL | Place of Origin: | China |
Product Description
Certification:ISO9001,ISO14001,CE,SGS,Rohs,REACH
Light Weight Aluminium Composite Sign Board Panel For Outdoor Advertise ECCA Standards
Raw Material:
1) Surface coating: PVDF. PE paint
2) Basic aluminum: high-strength aluminum alloy
3) Plastic core: No-toxic low density polyethylene
4) Adhesive film is made by SK Korea, more than 90 degrees.
Characteristic of Sign board panel:
1) Sign board can be directly applied for silk screen or digital printing, spray-paint and instant stick; it is easy to be cut, punched; it had great feasibility on processing, easy to be fixed to all claddings, including all shapes, angles, curves, radius, bending, joint, connection, etc. It can be finished by normal machines for metal and wood.
2) You can find colors alternative in MAXL with small quantity.
3) It has width of 1000mm - 2000mm; length is any on your requirement.
4) It paint performance is according to ECCA standards,5 years guarantee on PE coating, 15 years on PVDF coating. It is processed by UV ray and High temperature baking, so it is more hardness and good property in rub-resistance.
5) Panel thickness available: 2mm, 3mm, 4mm or 6mm
6) MAXL is supposed to screen printing, light weight but surprising rigidity, it is the best choice for outdoor advertise.
7) MAXL panel can be bend or curved by normal roller or bending machine, also could be customized as your ideas.
Application:
1) Advertisement and market applications as:
2) Display platforms, signboards, fascias and shop fronts etc.
3) Transport&Industry applications
Products Specification:
1) Panel Thickness: (2, 3, 4, 6mm)
2) Standard Width: (1000, 1250, 1500, 1550mm,2000mm)
3) Standard Length: (2440mm, 2500mm,3050mm, 4050mm)
4) Other sizes, colors as per customer\'s options can be accepted.
Panel Thickness |
Standard |
Unit |
2mm |
3mm |
4mm |
6mm |
Thickness of Aluminium |
DIN 1784 |
mm |
0.3 |
0.3 |
0.3 |
0.3 |
Aluminium thickness deviation |
DIN 1784 |
mm |
±0.02 |
±0.02 |
±0.01 |
±0.02 |
Weight |
Kg/m2 |
2.92 |
3.85 |
4.76 |
6.75 |
|
Tolerance in length |
DIN 16927/ISO 11833-1 |
mm |
﹣0/﹢2 |
﹣0/﹢2 |
﹣0/﹢2 |
﹣0/﹢2 |
Tolerance in width |
DIN 16927/ISO 11833-1 |
mm |
﹣0/﹢1.5 |
﹣0/﹢1.5 |
﹣0/﹢1.5 |
﹣0/﹢1.5 |
Tolerance in thickness |
DIN 16927/ISO 11833-1 |
mm |
±0.15 |
±0.15 |
±0.15 |
±0.15 |
Horizontal flatness |
DIN ISO 1101 |
mm |
6 |
5 |
4 |
4 |
Longitudinal roughness |
DIN ISO 1101 |
mm |
6 |
5 |
5 |
