Home > Products > Common Rail Pump Test Bench > 15KW 20HP High pressure Common Rail Pump Test Bench with Fuel tank capacity 80L 2000 bar
15KW 20HP High pressure Common Rail Pump Test Bench with Fuel tank capacity 80L 2000 bar
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
- Stackable Rack Energy Storage System Home energy storage system 5kWh 10kWh 15kWh and 20kWh
- Schneider Electric UPS
- Solar Generator With 5000W Inverter Portable Pull Rod LiFePO4 Battery Power Station
- 3000W Power bank EPS AC220V portable energy storage home power supply
- 5KW Outdoor Mobile Portable power station 220V Type-C DC12V DC5V Output UPS
- 500W portable UPS LFP Battery Solar Generator Backup Power Station
Product Details
Brand Name: | ADMTECK | Place of Origin: | China | Model Number: | ADM8719 |
Product Description
Certification:CE
15KW 20HP High pressure Common Rail Pump Test Bench with Fuel tank capacity 80L 2000 bar
Quick Details
1. Main motor power:15KW(20HP),18.5KW(25HP);
2. Working voltage: 3 phase 220/380/415V, 50HZ/60HZ;
3. Speed range: 0—4000rpm;
4. Supply pressure of the testing fuel: 0—4bar;
5. Fuel tank capacity: 80L;
6. Currency control range: 0—3A;
7. Injection width control range: 100--3000µs;
8. Injection volume range: 0.1ML—2000ML/1000times;
9. Backflow measuring range: 6—400L/H;
10. Pressure control range: 0—2000BAR;
11. Fuel temperature range: 30--60℃;
12. Cooling method: Compressor cooling
13. Cooling capacity: 5000KAL
Competitive Advantage:
Condition High Quality Reasonable Price Good after Service More Than 10 Years Experience Transport Terms: By Sea Packing : wooden boxADM8719 common rail test bench is our latest independent researched special device to test the performance of
high-pressure common rail pump and injector, it can test common rail pump and injector of BOSCH, SIEMENS,
DELPHI and DENSO. It tests the common rail injector by imported high precise flow meter sensor,can test piezo
injector. It controlled by industrial computer by real time. The data is also obtained by computer. 19 LCD screen
display makes the data more clear. ADM8719 can fulfill the remote assistance by internet and make the
maintenance easy to operate. Advanced technology, steady performance, precise measurement and convenient
operation.
Main Characteristics:
MAIN FUNCTIONS:
1. For the testing of the common rail pumps of BOSCH CP1,CP2,CP3, DENSO HP0,HP2,HP3,HP4, DELPHI and
SIMENS
2. Test the flow control valve of the common rail pumps.
3. Test the sealing of the CR injectors, the injection flow volume under full-loaded, emission point, idling and the
pre-injection, also back flow volume.
Main parameters:
1. Main motor power: 15KW(20HP),18.5KW(25HP);
2. Working voltage: 3 phase 220/380/415V, 50HZ/60HZ;
3. Speed range: 0—4000rpm;
4. Supply pressure of the testing fuel: 0—4bar;
5. Fuel tank capacity: 80L;
6. Currency control range: 0—3A;
7. Injection width control range: 100--3000µs;
8. Injection volume range: 0.1ML—2000ML/1000times;
9. Backflow measuring range: 6—400L/H;
10. Pressure control range: 0—2000BAR;
11. Fuel temperature range: 30--60℃;
12. Cooling method: Compressor cooling
13. Cooling capacity: 5000KAL
Technical Specification:
1. Power |
15KW 18.5Kw |
2. Rated Voltage |
220V/380V/415V |
3. Rated Voltage |
50/60HZ |
4. Speed Range |
0—4000rpm |
5. Supply pressure of the testing fuel |
0—4bar |
6. Fuel tank capacity |
80L |
7. Currency control range |
0—3A |
8. Injection width control range |
100--3000µs |
9. Injection volume range |
0.1ML—2000ML/1000times |
10. Backflow measuring range: |
6—400L/H |
11. Pressure control range |
0—2000BAR |
12. Fuel temperature range |
30--60℃ |
13. Cooling method |
Compressor cooling |
14. Cooling capacity: |
5000KAL |
Factory Pictures:
