Certification:CE/RoHS
Quick Detail:
►CRI: Ra> 80
►Sensor mode:infrared sensor
►Induction Angle:140°
►Induction Distance:5-8m
►Model Name: YC-FL-10W-01
►CCT: 2700 ~6500K
►Power Consumption: 10W
►Input Voltage: AC85 ~ 265V
►LED Brand:Epistar/Bridgelux
►Material: Aluminum
►Warranty:3 Years
Product feature:
►The main part of the lamp body adopts high-pressure die-casting aluminum crust,
which can make our products strong enough to prevent the impact and corrosion.
►High intensity toughened glass cover with special treatment, good transmission and
ultraviolet radiation function.
►High-purity aluminum reflector encapsulated integrated LED light source ensure
perfect radiation angle, huge lighting area
►Super heat-removal function, unique designed heat conductivity stuff can enhance
heat conductivity rate for LED and radiator.
►High efficiency and wonderful photo curve technology, using various kinds of methods
for the light distribution.
Specifications :
| Item Number | YC-FL10W-02 | Luminance | 2250±50lm |
| Lamp Material | Cast Aluminium | Color index | Ra > 80 |
| Beads type | COB | CCT | 2700-6500K |
| Brand chips | Epistar/Bridgelux | IP Rating | IP65 |
| Input Voltage | 85~265V | Storage temperature | -20°C-45°C |
| Frequence | 50/60HZ | Surface temperature | 50°C (test in 25°C ) |
| Power Fator | >0.9 | Lifespan | 50,000 hours |
| Power consumption | 30W | Lamp Size | L115*W200*H81mm |
| Power Efficiency | >85% | Box Size | L125*W98*H135mm |
| Beam Angle | 120° | Box Weight | 0.62KG |
Lamp Size:
Package information:
| Box | Carton | |||||
| Item Number | Measurement(mm) | Gross weight | Pcs/box | Measurement(mm) | Gross weight | Pcs/carton |
| YC-FL-10W-01 | L185*W358*H130 | 1.24 kg | 1 | L495*W590*H290 | 16.2 kg | 12 |
Applications:
Lighting for building,bridges, sculptures,billboards,parking
