100W WaterProof Induction Ceiling Lighting Ra80 For Supermarket

Delivery Time:Within 15 working days , depend on QTY
Certification:CE,ROHS,UL

 100W WaterProof Induction Ceiling Lighting Ra80 For Supermarket

Quick Detail:

Item Type: Induction Ceiling light     Lighting Source: Induction Lamp Square/Round Series

Input Voltage(V):90-305V ,220V       Lamp Power(W): 40W,60W, 80W, 100W

Lamp Luminous Efficiency: 75-85lm/W     CRI:Ra>80

Color Temperature(CCT): 2700-6500K      Working Temperature(℃):-35 - 50

Working Lifetime (Hrs): 100000 hours      IP Grade: IP65

Lamp Body Material: Cold-rolled steel plate, imported aluminum reflector,bar grating cover.

Start way : Quick instant on /of           High Power Factor: >0.98

Place of Origin: Changzhou , China   Certifications: CE, ROHS , UL

Brand Name: NSL                    Model Number: NSL-GS001

Description:

Housing: Cold-rolled steel plate,electrostatic spray surface treatment,high quality powder coat finish,good for heat elimination. Reflector: High Purity Mirror imported aluminum reflector ensures high-output luminous flux,  ,beautiful and durable. Glass: Bar grating cover. New type silicon rubber sealing ring ensure the aging resistant of silicon rubber Wattage Range: Big range voltage from 90V to 305V available. Color:  2700-6500K available. Lamp Source: NSL-DP series square / Round type low frequency induction lamp source,with 120-300 Wattage, 90-305 input voltage,2700-6500K available, 100000 hours lifespan . High purity rare earth fluorescent phosphor with high luminous efficiency and low light degradation. Light Tube thickness is more than 0.8MM. Magnetic ring is high temperature resistance with high inductance, Long lifespan. Electronic Ballast : Rational distribution of each components,imported high quality capacitor, IC chips, MOS tube. Three EMC filters against interfering signal.

Photometric Curve                                                            Fixture Dimension

Applications:

1. Marketplace, supermarket, hotel, office,meeting rooms, class room , department store,show room, villa residence and etc .

2. Use 40/60/80/100W square / Round tubular induction lamp with high lighting efficiency (75-80Lm/w) and lumen maintenance at 70% at 60,000 hours and rated life of 100,000 hours at 65%, about 12 years on burning 8000 hours per year.

3. Electronic ballasts features high power factor(>0.95), flickering free, and constant output wattage, safety protection and meets FCC non-consumer requirements with low and extremely low EMI designs.

Specifications:

Ceiling Light Induction Lamp Fixture

Brand Name	NSL	Fixture Code	NSL-GS001
Wattage:	40W-100W	Fixture Dimension(mm)	600*600*126mm/pcs
Weight	6.5/5.6 kgs	Lifespan	100000hours
Voltage:	90V~305V / 220 V	Install way	Embedded  /      Surface Mounting
Power factor:	>0.98	CRI:	Ra> 80
Color Tem:	2700~6500K	Packing Dimension(mm)	620*620*160mm/pcs
Application:	Marketplace, supermarket, hotel, office,meeting rooms, class room , department store,show room, villa residence and etc

Competitive Advantage:

(1) Long performance life: Life up to 60,000-100,000 hours.

(2) High energy efficiency: Luminous effeciency ≥80-90Lm/W, save 50-80% energy.

(3) Low light falling: ≤5% in 2000 hours.

(4) Low temperature: normal working temperature≤80°c.

(5) No flicker: Operating frequency is 140 KHz-250KHz.

(6) Full color temperature: 2700K-6500K.

(7) High power factor: ≥0.98.
