Glass Fiber / Plastic Compounding Line With Parrel Twin Screw Extruder 80kg/h

Name: Glass Fiber / Plastic Compounding Line With Parrel Twin Screw Extruder 80kg/h
Brand: PURUI
SKU: 149375666
Availability: InStock

Purui Plastics&rubbe Co.,ltd.

Glass Fiber / Plastic Compounding Line With Parrel Twin Screw Extruder 80kg/h thumbnail-1

Glass Fiber / Plastic Compounding Line With Parrel Twin Screw Extruder 80kg/h photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

PURUI

Place of Origin:

China

Model Number:

TSSK

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name PURUI

Place of Origin China

Model Number TSSK

Delivery Time:50 working days after getting deposit
Certification:CE

TSSK75 plastic compounding line for filling Nylon 6 with glass fiber

Quick Detail:

· Extruder model: parrel twin screw extruder

· Material of screw: W6Mo5Cr4V2,Bimetallic

· High-performance degassing

· See machine running when come to our factory

· Engineer supply when you buy the machine

· Design machine according to your material

· One year guarantee but offer all life after sales service

Description:

A. Features of TSSK75 plastic compounding line for filling Nylon 6 with glass fiber:

1.modular structure and fully intermeshed screw of great self-cleaning ablity and degassing property

2.Bimetallic liner for extruder barrel,with superior wear resistance and corrosion resistance

3.Wide range of application by simply adjust configuration according to the detailed processing.

B. Applications fields of TSSK75 plastic compounding line for filling Nylon 6 with glass fiber:

Our parallel co-rotating twin screw extruder specially designed for filler modified resin which have excellent mixing performance,good self-cleaning performance and flexible modular configuration characteristivs which make them suitable for processing different types of material.

This screw of the co-rotation twin-screw exturder are composed of multi-sections. The raw material obtain optimization of compounding after undertaking high speed, high torque, compounding in the barrels, fixed feeding system, it can input glass fibers, additives,high density master batch etc.

Note: depending on different material properties, various downstream equipments are needed.

Filling modification:

CaCo3

talcum powder

barium sulfate

titanium pigment

ceramic powder

Wood flour/plant fiber

Other inorganic filler

Reinforce modification:

short glass fiber

long glass fiber

carbon fiber

Other whisker

Degradation master-batch

Other special functions master-batch

Blending modification:

thermoplastic material/TPE

polymer alloys

Cable material :

PVC cable material

zero halogen cable material

PE TR-XLPE,NDH

PE cross-linking cable material

Special cable material

C. Specifications of plastic compounding line:

Technical parameter of plastic compounding line (normal)

Model	TSSK-20	TSSK-30	TSSK-35	TSSK-50	TSSK-65	TSSK-72	TSSK-92
Screw diameter(mm)	21.7	30	35.6	50.5	62.4	71.2	91
Rotary speed(rpm))	600	400	400/600	400/500	400/500	400/500	400/500
Mainmotor power(kw)	4	11	11/15	37/45	55/75	90/110	220/250
L/D	32-40	28-48	32-48	32-48	32-48	32-48	32-40
Capacity(kg/h)	2-10	5-30	10-80
