Color Steel Aluzinc Panel Standing Seam Roll Forming Equipment Hydraulic System
Feature:
This producing line uses galvanized steel sheet, colored armor plate or aluminum plate as the material
plate.
The products of it are used as the roof tile and wall panel outside of building, to increase the beauty and
durability of the roof tile and wall panel. This line has no limit on processing length; you can set several
different data on thecomputer control cabinet according to your own need. After pressing the button
\"Confirm\", the machine can produce the panel automatically according to the set data. The molding
plate surface smooth and not easy to be marked when it is being stamped. So it is easy to install.
The product conforms to National Steel Construction Building Standard.
Technical parameter:
|
Name |
Item |
Specification |
|
Coil requested |
Material |
Color steel, galvanized steel |
|
Thickness |
0.3-0.7mm |
|
|
Tensile strength |
235Mpa |
|
|
Decoiler(1 unit) |
Type and weight capacity |
Manual decoiler, 5T |
|
Inner diameter |
498-508mm |
|
|
Outer diameter |
Max:1800mm |
|
|
Rollforming machine (1 unit) |
Rolling speed |
15m/min |
|
Motor |
7.5KW, 3phase, 60Hz, 380V |
|
|
Rolling step |
18 |
|
|
Driving system |
Chain transmission |
|
|
Structure of machine body |
Entire wall steel structure |
|
|
Material of roller |
45# steel, chromed thickness0.05mm |
|
|
Diameter of shaft |
80mm |
|
|
Dimession |
Abt.13m*1.8m*1.6m |
|
|
Weight |
Abt.12T |
|
|
Electric control cabinet (1 unit) |
Main component |
PLC, frequency convertor, touching screen, encoder |
|
Cutting and length measurement |
Automatic stop to cut, encoder |
|
|
Brand |
From Japan, can be chosen by client |
|
|
Hydraulic station (1 unit) |
Power and strength |
3.5KW, 16Mpa |
|
Cutting machine(1 unit) |
Material of blade |
Cr12, heatment and hardness up to HRC58-62 |
|
Cutting type |
Hydraulic cutting |
|
|
Run out table (1 unit with 4pics) |
Size |
1.2m*0.7m*1.2M |
Working flow:
Passive decoiler----Feeding---Rollforming----Hydraulic cutting----Run out table
Application:
The roof panel used as the roofing of factory, garage,warehouse, reliable and safety installation is easy to realize. Good toughness: with super toughness, Tere is no necessary to do any treatment amontg the nail hole, it is sealing and can prevent leaking water. Long life: life ≥ 25 years, is an alternative to steel tile. Corrosion resistance: strong acid, alkali, salt, anti-static, anti-vapor corrosion, etc. Noise performance: noise performance is good, away from the noise.
