Anti - Theft Security Plexiglass 58m AM Detection eas tagging systems For Jewerlly Store
58MHZ AM RETAIL LOSS PREVENSION EAS SYSTEM SANZHAI033
The detection range of Sanzhai033 is the largest in field of the EAS system.
the product orientation is High- end retail stores.
Specification: with the function of independent channel alarming and special PC software debugging.
The detection range of hard tags can reach 3.2m, and the soft label can reach 1.8m.
Technical parameters:
|
Input voltage: |
220VAC ± 10% 50Hz |
material: |
imported Plexiglass |
|
Rated power: |
≤ 20W |
fuse: |
250V 1A sb |
|
Dimension for antenna: |
1576× 430× 20mm |
weight: |
21Kg |
|
Dimension for controller: |
395× 200× 120mm |
Weight for controller: |
8Kg |
|
Detection width: |
320cm MAX |
Detection height: |
180cm |
|
Humidity : |
≤ 95% RH |
Working Temperature: |
-15℃ ～ 60℃ |
|
Alarm indication: |
sound and light |
Contact output: |
24V 100mA |
|
Signal processing mode : |
DSP |
Synchronous interface: |
3 in a controller |
|
Useful life: |
More than 15 years |
Time for trouble-free: |
60, 000H |
Detection range:
DR tag: 75cm- 1.1cm for one each side
Pencil tag(33mm magnet): 120cm- 140cm
Pencil tag(39mm magnet): 140cm- 160cm
Pencil tag(45mm magnet): 160cm- 180cm
Description
1. The detection range of Sanzhai033is the largest in field of the EAS system.
the product orientation is High-end retail stores.
2. with the function of independent channel alarming and special PC software debugging. The detection range of hard tags can reach 3.2m, and the soft label can reach 1.8m.
3. the system can be adjust to transmitter or receiver and mono, the protection range can reach 7.5- 1.1m for soft label, and 1.6- 1.8m for hard tag ( magnetic bar is 45mm).
4. A main controller can carry 3 antennas,and alarm in single channel.
5.The main controller is separated from the antenna,can be adjusted by the PC software
