30 Degree DMX LED Stage Light Of Red / Green / Blue / White Outdoor Stage Lighting

30 Degree DMX LED Stage Light Of Red / Green / Blu / White LED Lighting

Quick Detail:

6 1W Red, 6 1W Green, 6 1W Blue, 6 1W White

Built-in Li-ion battery for 6 -18h of operation

Wireless DMX, Auto, Manual, Sound

CE, RoHS

Specifications:

Working Mode:

DmxMode ---To receive data from DMX controller or Master unit.

AutoMode --- The unit will automatically chase through the different colors (18 effects ).

MaulMode --- The unit will work manually as desired.

SoudMode --- The unit will react to sound, chasing through the built in programs.

WIRELES ID SETUPS --- To set wireless ID.

Button and LED indicators positions:

High power individual controllable LED, using 4 buttons and LCD display for operation menu.

Press ESC to get back to last menu.

Press ENTER to get into function menu.

Press Down, UP to edit current parameter.

Note:

When to receive wireless dmx signal, through WIRELESS ID SETUPS, you can set ID code, when

the color of the ID indicators from both transmitting and receiving ends are the same, the

communication is setup successfully.

Wireless ID setup

Press SETUP, UP OR DOWN at present mode to display current ID, press again to setup new ID, ID value will be added 1 more by pressing one time, ID indicator color will change according one by one.

Working Status:

ID code and LED color corresponding relationship:

Slave Setup

Any working modes under DmxMode can be Slave mode, if choose slave mode, its output is the same as that of the Master Unit.

DMX Control Channels Table (DMX Mode 0)
