Help CenterSuperior Interness Yellow FR4 Sheet
Related Products
-
FR4 Yellow Plastic TubeUS$ 20 - 20MOQ: 500 Metric Tons -
Good Intertness FR4 Fiber Glass Epoxy SheetUS$ 5 - 5MOQ: 1000 Pieces
-
Food Safe, Noise Reduction Mc Nylon SheetUS$ 50 - 50MOQ: 500 Pieces
-
Good Self-lubricating Properties Antistatic POM SheetUS$ 50 - 50MOQ: 300 Pieces
-
Good Fatigue Resistance Antistatic POM SheetUS$ 50 - 50MOQ: 100 Pieces
I.Material Introduction
Define and purpose
This laminated product is formed through heat pressing after electric industry alkali glass cloth dips into the epoxy phenolic resin. It has high mechanic and dielectric performance, and applicable as insulation structural components for electromechanical/electrical equipment, as well as used under damp environmental conditions and transformer oil .
Technical requirement for surface
The surface of laminated board should be flat and smooth, no bubble, no wrinkle, no delamination or crackle, and properly free from other defects such as scrape, impress, dirty spot and uneven color, but a little color patches is allowed.
II.Related products:
♦ G10/G11 Epoxy Glass Fiber Sheet
Color: Green
G10/G11 is a composite material combined with glass fiber cloth and epoxy resin, which can bear great pressure without damage and deformation. G10/G11 can’t be permeated by vapor and liquid and it owns good insulation and acid& alkali resistance characteristics.G10 can be FR4 by adding flame retardant but it becomes G11 by improving thermal flexural properties.
♦ Antistatic Epoxy Fiber Glass Sheet
Color: Black
Advantages: high density, low absorption, good heat resistance and dimension stability, good dielectric properties and mechanical strength.
Application: Be used for various testing jigs, flat of precise instrument and installment of electrical products
Surface resistivity: after finishing moisture-proof C-96/35/90: 106 ~109Ω
after high temperature E-24/125: 106 ~109Ω
Volume resistivity: after finishing moisture-proof C-96/35/90：4×108 Ω-cm
after high temperature E-24/125: 2×106 Ω-cm
III.Characteristic
The surface of laminated board should be flat and smooth, no bubble, no wrinkle, no delamination or crackle, and properly free from other defects such as scrape, impress, dirty spot and uneven color, but a little color patches is allowed.
IV.Application
1.Chemical machine parts , general machine parts and gear ,and generators, Pads, base, baffle etc..
2.Generator ,transformer, fixture, inverter, motor and electric insulation component.
